Product Description
Discover the 2020 XCMG XE60WA, a robust and reliable excavator currently available in Peking, China. This machine is known for its exceptional performance and powerful engine, making it an ideal choice for a variety of construction and excavation projects. The XE60WA delivers strong operational efficiency, ensuring that every task is completed with precision and power. Ideal for business owners looking to enhance their fleet, this excavator offers a cost-effective solution without compromising on quality or capability.
- Year: 2020
- Brand: XCMG
- Model: XE60WA
- Location: Peking, China
| Specifications | Value |
|---|---|
| No. | 1130196 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5900 |
| Bucket capacity (m³) | 0.23 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | YANMAR 4TNV98-EXPXG |
| Rated power (kw/rpm) | 41.5/2400 |
| Total displacement (L) | 3.319 |
| Maximum torque (N.m) | 201/1800 |
| Forward speed (Km/h) | 26.4/10.5 |
| Rotation speed (rpm) | 8.5 |
| Climbing ability (%) | 56 |
| Bucket digging force (kN) | 42.8 |
| Rod digging force (kN) | 25.8 |
| Minimum turning radius (m) | 4.69 |
| Maximum flow of main pump (l/min) | 2 x 60 |
| Main pump type | Two plunger pumps |
| Working Hydraulic Circuit (Mpa) | 22 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 120 |
| Total transport length (mm) | 6230 |
| Total transport width (mm) | 1925 |
| Total transport height (mm) | 2850 |
| Counterweight ground clearance (mm) | 970 |
| Wheelbase (mm) | 2100 |
| Wheel base (mm) | 1600 |
| Minimum ground clearance (mm) | 290 |
| Back end turning radius (mm) | 1665 |
| Onboard width (mm) | 1925 |
| Maximum digging radius (mm) | 6120 |
| Maximum excavation radius (mm) | 5910 |
| Maximum digging depth (mm) | 3520 |
| Maximum excavation height (mm) | 5830 |
| Maximum unloading height (mm) | 4240 |
| Maximum vertical digging depth (mm) | 2400 |
| Maximum digging depth (mm) | 3520 |
| Dodging plate width × height (mm) | 390 (height) |
