Product Description
This 2021 XCMG XE60WA wheeled excavator offers reliable performance for construction and material handling operations. With approximately 3,600 operating hours recorded as of April 2021, this machine represents a well-maintained mid-life unit suitable for contractors seeking proven XCMG engineering at competitive value.
The XE60WA combines the mobility of wheeled design with excavation capability, making it ideal for urban projects, road maintenance, and sites requiring frequent relocation. XCMG's established reputation in the Chinese heavy equipment market ensures parts availability and service support.
Key features include:
- Wheeled configuration for enhanced mobility
- Moderate hour count indicating substantial service life remaining
- Currently located in Henan Province, China
- Suitable for municipal, utility, and general construction applications
This unit is available for immediate inspection and purchase. Contact us for detailed specifications, current condition assessment, and shipping arrangements to your location.
| Specifications | Value |
|---|---|
| No. | 1074593 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5900 |
| Bucket capacity (m³) | 0.23 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | YANMAR 4TNV98-EXPXG |
| Rated power (kw/rpm) | 41.5/2400 |
| Total displacement (L) | 3.319 |
| Maximum torque (N.m) | 201/1800 |
| Forward speed (Km/h) | 26.4/10.5 |
| Rotation speed (rpm) | 8.5 |
| Climbing ability (%) | 56 |
| Bucket digging force (kN) | 42.8 |
| Rod digging force (kN) | 25.8 |
| Minimum turning radius (m) | 4.69 |
| Maximum flow of main pump (l/min) | 2 x 60 |
| Main pump type | Two plunger pumps |
| Working Hydraulic Circuit (Mpa) | 22 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 120 |
| Total transport length (mm) | 6230 |
| Total transport width (mm) | 1925 |
| Total transport height (mm) | 2850 |
| Counterweight ground clearance (mm) | 970 |
| Wheelbase (mm) | 2100 |
| Wheel base (mm) | 1600 |
| Minimum ground clearance (mm) | 290 |
| Back end turning radius (mm) | 1665 |
| Onboard width (mm) | 1925 |
| Maximum digging radius (mm) | 6120 |
| Maximum excavation radius (mm) | 5910 |
| Maximum digging depth (mm) | 3520 |
| Maximum excavation height (mm) | 5830 |
| Maximum unloading height (mm) | 4240 |
| Maximum vertical digging depth (mm) | 2400 |
| Maximum digging depth (mm) | 3520 |
| Dodging plate width × height (mm) | 390 (height) |
