Product Description
Discover the 2023 XCMG XE60WA, a high-quality used wheeled excavator with a proven track record. This machine, located in Anhui, China, has been meticulously maintained and is ready for your next project. With 3600 hours of operation, it remains in excellent condition, offering reliability and efficiency. The XE60WA is known for its robust design, making it ideal for various construction and excavation tasks. Trust in the durability and performance of this XCMG model to meet your industrial needs.
- Year: 2023
- Brand: XCMG
- Model: XE60WA
- Operating Hours: 3600
- Location: Anhui, China
| Specifications | Value |
|---|---|
| No. | 1086541 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5900 |
| Bucket capacity (m³) | 0.23 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | YANMAR 4TNV98-EXPXG |
| Rated power (kw/rpm) | 41.5/2400 |
| Total displacement (L) | 3.319 |
| Maximum torque (N.m) | 201/1800 |
| Forward speed (Km/h) | 26.4/10.5 |
| Rotation speed (rpm) | 8.5 |
| Climbing ability (%) | 56 |
| Bucket digging force (kN) | 42.8 |
| Rod digging force (kN) | 25.8 |
| Minimum turning radius (m) | 4.69 |
| Maximum flow of main pump (l/min) | 2 x 60 |
| Main pump type | Two plunger pumps |
| Working Hydraulic Circuit (Mpa) | 22 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 120 |
| Total transport length (mm) | 6230 |
| Total transport width (mm) | 1925 |
| Total transport height (mm) | 2850 |
| Counterweight ground clearance (mm) | 970 |
| Wheelbase (mm) | 2100 |
| Wheel base (mm) | 1600 |
| Minimum ground clearance (mm) | 290 |
| Back end turning radius (mm) | 1665 |
| Onboard width (mm) | 1925 |
| Maximum digging radius (mm) | 6120 |
| Maximum excavation radius (mm) | 5910 |
| Maximum digging depth (mm) | 3520 |
| Maximum excavation height (mm) | 5830 |
| Maximum unloading height (mm) | 4240 |
| Maximum vertical digging depth (mm) | 2400 |
| Maximum digging depth (mm) | 3520 |
| Dodging plate width × height (mm) | 390 (height) |
