Product Description
Engineered with precision hydraulics and a robust Yanmar 4TNV94L engine, this 2020 XCMG XE65D delivers 39.8kW of reliable power for demanding excavation tasks. Operating at 6 tons with a 6,200kg working weight, this compact excavator combines exceptional digging force—48.3kN bucket force and 32.5kN arm force—with a sophisticated hydraulic system featuring dual main pumps (138/143 L/min) and 24.5MPa main overflow pressure. Built in Xuzhou, China, the XE65D demonstrates XCMG's commitment to engineering excellence through its water-cooled 4-cylinder configuration and optimized hydraulic circuits.
- Maximum digging reach of 6,130mm with 3,830mm depth capability
- Rexroth/Ogail main pump system ensuring consistent hydraulic performance
- Standard hydraulic breaker pipeline for enhanced versatility
- 35° climbing ability with 32.5kPa ground pressure for superior maneuverability
- Compact dimensions (5,860mm length) ideal for confined job sites
- Currently available in Maoming, Guangdong
With 110L fuel capacity and proven 3.054L displacement, this machine represents dependable mid-range excavation performance backed by established manufacturing standards.
| Specifications | Value |
|---|---|
| No. | 1034056 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 6200 |
| Bucket capacity (m³) | 0.09-0.25 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.5 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 48.3 |
| Rod digging force (kN) | 32.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 24.5 |
| Maximum flow of main pump (l/min) | 138/143 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexley/Ogail |
| Working Hydraulic Circuit (Mpa) | 22 |
| Pilot Oil Circuit (MPa) | 2.6 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5860 |
| Total transport width (mm) | 2000/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2460 |
| Back end turning radius (mm) | 1660 |
| Track gauge (mm) | 1600/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 2053/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 2000*365/1920*340 |
