Product Description
Built for the toughest jobsites, this 2022 XCMG XE700C hydraulic excavator stands as a proven workhorse in the 70-ton class. Powered by a robust CUMMINS QSX15 engine delivering 336kW at 1800 rpm, this machine combines raw power with exceptional reliability. With a working weight of 68,000 kg and bucket capacity ranging from 3.1 to 3.5 m³, it tackles heavy-duty excavation with remarkable efficiency.
Engineered in Xuzhou, China, this excavator features dual plunger pumps providing 2×450 L/min flow capacity, ensuring responsive hydraulic performance across all functions. Its impressive reach extends to 11,580 mm maximum digging radius and 6,900 mm maximum digging depth, while delivering 370 kN bucket digging force and 330 kN rod digging force. The water-cooled, turbocharged 6-cylinder engine with air-to-air cooling maintains optimal performance in demanding conditions.
Currently located in Huizhou, Guangdong, this recently manufactured excavator demonstrates XCMG's commitment to durability. With minimal operating hours since 2022, it represents an opportunity to acquire near-new performance at exceptional value—a machine built to last decades, not just years.
| Specifications | Value |
|---|---|
| No. | 1039603 |
| Tonnage (tons) | 70 |
| Working weight (kg) | 68000 |
| Bucket capacity (m³) | 3.1-3.5 |
| Boom length (mm) | 6600 |
| Rod length (mm) | 2900 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | CUMMINS QSX15 |
| Rated power (kw/rpm) | 336/1800 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 15 |
| Working form | Turbocharged/air-to-air cooling |
| Ground specific pressure (Kpa) | 99.1 |
| Rotation speed (rpm) | 7 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 370 |
| Rod digging force (kN) | 330 |
| Travel speed (km/h) | 4.2/3.0 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*450 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25.5 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 980 |
| Hydraulic Tank (L) | 455 |
| Engine Oil changes (L) | 48 |
| Total transport length (mm) | 11940 |
| Total transport width (mm) | 4280 |
| Total transport height (mm) | 4700 |
| Counterweight ground clearance (mm) | 1552 |
| Minimum ground clearance (mm) | 853 |
| Minimum turning radius of front working device (mm) | 4750 |
| Back end turning radius (mm) | 3900 |
| Track gauge (mm) | 2800/3350 |
| Track plate width (mm) | 650 |
| Track ground length (mm) | 4680 |
| Maximum digging radius (mm) | 11580 |
| Maximum digging depth (mm) | 6900 |
| Maximum excavation height (mm) | 11350 |
| Maximum unloading height (mm) | 7370 |
| Maximum vertical digging depth (mm) | 5500 |
