Product Description
Built to endure the toughest job sites, this 2016 XCMG XE75C mini excavator delivers proven performance with over seven years of reliable operation. Operating at 7 tons with a working weight of 7,450 kg, this Chinese-manufactured workhorse combines robust construction with efficient productivity. Powered by a dependable V2607 engine generating 43 kW at 2000 rpm, it provides consistent power delivery across demanding applications.
Currently located in Hunan, this machine demonstrates XCMG's commitment to durability through its comprehensive specifications:
- Maximum digging depth of 4,020 mm with 6,260 mm reach
- Bucket digging force of 57 kN and 0.30 m³ capacity
- 160 L/min main pump flow for responsive hydraulics
- Compact transport dimensions: 6,150 mm × 2,230 mm × 2,685 mm
- 130 L fuel tank and 115 L hydraulic reservoir for extended operation
With maximum excavation height reaching 7,085 mm and tractive force of 68.32 kN, this proven XE75C continues to demonstrate why XCMG equipment remains a trusted choice for contractors worldwide. Ready for immediate deployment in your fleet.
| Specifications | Value |
|---|---|
| No. | 1011979 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
