Product Description
With a robust 7-ton working weight and a reliable V2607 engine, this 2016 XCMG XE75C excavator from Zhejiang Shaoxing has proven its durability over the years. Boasting a rated power of 43 kW at 2000 rpm, it delivers consistent performance in demanding environments. The machine's 0.3 m³ bucket capacity and 57 kN bucket digging force ensure efficient excavation, while its 5.4 km/h travel speed enhances mobility on the job site.
- Built to last with a 7450 kg working weight and 33.5 Kpa ground specific pressure
- Proven workhorse featuring a 2.6 L displacement engine and 160 l/min maximum flow of the main pump
- Maximum digging depth of 4020 mm and maximum unloading height of 516 mm for versatile operations
- Equipped with a 130 L fuel tank and 115 L hydraulic tank for extended operational hours
| Specifications | Value |
|---|---|
| No. | 1028036 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
