Product Description
Engineered with precision hydraulics and a robust Kubota V2607 engine, this 2016 XCMG XE75C mini excavator delivers 43 kW of rated power at 2000 rpm with a maximum torque of 255.8 N.m. Built on proven Chinese manufacturing standards, this 7-ton machine combines a 160 L/min main pump flow rate with exceptional digging force—57 kN bucket force and 38 kN arm force—to handle demanding excavation tasks efficiently.
- Operating weight: 7,450 kg with 0.30 m³ bucket capacity
- Maximum digging reach: 6,260 mm; digging depth: 4,020 mm
- Superior vertical digging depth: 2,920 mm for confined spaces
- Compact transport dimensions: 6,150 × 2,230 × 2,685 mm
- Dual travel speeds: 5.4/2.9 km/h for versatile site mobility
- 130 L fuel tank and 115 L hydraulic reservoir for extended operation
- Low ground pressure: 33.5 kPa minimizes surface damage
Currently located in Maoming, Guangdong, this machine represents XCMG's commitment to reliable construction equipment with proven performance metrics across residential, commercial, and utility applications worldwide.
| Specifications | Value |
|---|---|
| No. | 1030251 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
