Product Description
Engineered with a robust V2607 engine delivering 43kW at 2000rpm and 255.8N.m maximum torque, this 7-ton excavator demonstrates XCMG's commitment to hydraulic precision and mechanical reliability. The 160L/min main pump flow rate ensures responsive control across all operations, while the 0.30m³ backhoe bucket generates 57kN digging force and 38kN rod force for demanding excavation tasks.
Built in China to exacting standards, the XE75C combines a 7,450kg working weight with exceptional reach capabilities: 6,260mm maximum digging radius and 4,020mm digging depth. The compact transport dimensions (6,150×2,230×2,685mm) facilitate easy mobilization, while the dual-speed travel system (5.4/2.9km/h) optimizes site productivity.
Key technical specifications include:
- Maximum tractive force: 68.32kN
- Ground specific pressure: 33.5kPa for reduced surface impact
- Fuel capacity: 130L for extended operation
- Hydraulic tank: 115L supporting consistent system performance
- 10rpm rotation speed for precise positioning
Currently located in Shanghai, this 2016 unit represents proven mid-size excavator technology suitable for construction, utility, and civil engineering applica
| Specifications | Value |
|---|---|
| No. | 1031840 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
