Product Description
Proven in demanding conditions since 2017, this XCMG XE75C excavator demonstrates the durability that has made it a reliable workhorse across global construction sites. Operating at 7 tons with a working weight of 7,450 kg, this machine delivers consistent performance through its robust V2607 engine, generating 43 kW at 2000 rpm and 255.8 N.m of maximum torque. Built to last, it combines a 0.30 m³ bucket capacity with impressive digging force—57 kN bucket force and 38 kN rod force—handling tough excavation tasks with proven efficiency.
Currently located in Luzhou, Sichuan, this China-manufactured excavator features a maximum digging depth of 4,020 mm and a reach of 6,260 mm, making it versatile for medium-scale operations. With a 130-liter fuel tank and 160 l/min hydraulic flow, it maintains productivity throughout extended shifts. Compact transport dimensions (6,150 × 2,230 × 2,685 mm) ensure easy mobilization between job sites. Years of field-tested reliability confirm this XE75C as a dependable investment for contractors seeking proven engineering without compromise.
| Specifications | Value |
|---|---|
| No. | 1029961 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
