Product Description
Built for precision work on demanding job sites, this 2019 XCMG XE75C mini excavator delivers reliable performance across grading, trenching, and utility installation projects. Operating at 7 tons with a 43kW V2607 engine, this compact machine combines a 6,260mm maximum digging radius with 4,020mm digging depth to handle confined spaces without sacrificing reach. The 0.30m³ backhoe bucket generates 57kN digging force, while 38kN rod force ensures efficient material handling in clay, gravel, and mixed soil conditions.
- 7,450kg working weight provides stability during heavy digging operations
- 160L/min hydraulic flow supports responsive attachment control
- 5.4km/h travel speed enables quick repositioning between work zones
- 2,230mm transport width allows trailer transport and access through standard gates
- 130L fuel tank extends runtime on remote sites
- 33.5kPa ground pressure minimizes surface damage on finished landscapes
Currently located in Lishui, Zhejiang, this machine is serviced and ready for immediate deployment on your next excavation project.
| Specifications | Value |
|---|---|
| No. | 1050862 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
