Engineered with precision, this 7-ton excavator delivers exceptional performance through its v2607 engine, generating 43kW at 2000rpm with a maximum torque of 255.8 N.m. Hydraulic efficiency stands at the core of the XE75C design, featuring a 160 l/min main pump flow rate that powers a bucket digging force of 57kN and rod digging force of 38kN. Operating weight of 7,450kg provides optimal stability while maintaining a ground specific pressure of just 33.5 Kpa, ensuring minimal surface impact across varied terrain.
Performance specifications include:
- Maximum digging reach: 6,260mm with 4,020mm depth capability
- Maximum excavation height: 7,085mm for superior vertical range
- 0.30m³ bucket capacity with backhoe configuration
- Dual travel speeds: 5.4/2.9 km/h for operational flexibility
- 130L fuel tank and 115L hydraulic tank for extended runtime
Compact transport dimensions (6,150 x 2,230 x 2,685mm) facilitate easy mobilization between job sites. Maximum tractive force of 68.32kN ensures reliable performance in demanding applications. Currently located in Yunnan, China, this machine represents proven XCMG manufacturing standards with comprehensive technical documentati
| Specifications | Value |
|---|---|
| No. | 1025159 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
