Product Description
Engineered with precision, this 7-ton mini excavator delivers exceptional performance through its robust V2607 engine, generating 43kW at 2000 rpm with 255.8 N·m maximum torque. The advanced hydraulic system features a 160 L/min main pump capacity, translating into impressive 57kN bucket digging force and 38kN rod digging force—specifications that define reliability in demanding excavation work.
Built on XCMG's proven XE75C platform, this 2020 model combines a compact 6150mm transport length with serious capability. Operating weight of 7,450kg ensures stability while maintaining low 33.5 Kpa ground pressure for minimal site disturbance. The 0.30m³ bucket handles material efficiently across a 6,260mm maximum digging radius and 4,020mm digging depth.
Key technical advantages include:
- Maximum excavation height of 7,085mm for superior reach
- Dual-speed travel system: 5.4/2.9 km/h for versatility
- 130L fuel capacity with efficient 2.6L displacement engine
- 10 rpm rotation speed enabling precise positioning
- Currently located in Hubei, China, ready for global deployment
| Specifications | Value |
|---|---|
| No. | 1028887 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
