Product Description
Built for productivity, this 2020 XCMG XE75C mini excavator delivers 7-ton performance with a 0.30 m³ backhoe bucket designed for immediate deployment on construction, utility, and landscaping sites. Powered by a reliable V2607 engine producing 43 kW at 2000 rpm, this machine combines 57 kN bucket digging force with 38 kN arm force to tackle trenching, foundation work, and material handling tasks without hesitation.
Currently located in Zhejiang Jinhua, China, this compact workhorse offers exceptional reach with a 6,260 mm maximum digging radius and 4,020 mm digging depth—ideal for utility installation and site preparation projects. Transport dimensions of 6,150 × 2,230 × 2,685 mm ensure easy mobilization between job sites.
- Working weight: 7,450 kg for stable operation
- Hydraulic system: 160 L/min main pump flow for responsive controls
- Fuel capacity: 130 L tank for extended operation
- Travel speed: 5.4 km/h for efficient repositioning
- Maximum unloading height: 5,160 mm for truck loading
Ready to dig from day one—comprehensive specifications confirm this machine is prepared for demanding site conditions.
| Specifications | Value |
|---|---|
| No. | 1029426 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
