Product Description
Powered by a reliable Yanmar V2607 engine delivering 43 kW at 2000 rpm, this 2021 XCMG XE75C mini excavator combines precise hydraulic control with operator-centric design. Weighing 7,450 kg with a 0.30 m³ backhoe bucket, this 7-ton machine offers exceptional stability through its 33.5 kPa ground pressure distribution, minimizing ground disturbance while maximizing digging performance.
Operators benefit from enhanced visibility and ergonomic controls that reduce fatigue during extended shifts. Key performance specifications include:
- Maximum digging reach: 6,260 mm with 4,020 mm depth capability
- Bucket digging force: 57 kN; arm digging force: 38 kN
- 160 L/min hydraulic flow for responsive operation
- Dual travel speeds (5.4/2.9 km/h) for versatile site mobility
- Compact transport dimensions: 6,150 × 2,230 × 2,685 mm
- 130 L fuel capacity for extended runtime
Currently located in Yichun, Jiangxi, this Chinese-manufactured excavator delivers reliable performance for construction, landscaping, and utility applications where operator comfort directly impacts productivity.
| Specifications | Value |
|---|---|
| No. | 1031046 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
