Product Description
Expand your operational capacity with this 2022 XCMG XE75C mini excavator, currently located in Luzhou, Sichuan. Built for contractors running multiple jobsites simultaneously, this 7-ton machine delivers consistent performance as a fleet backup or dedicated light-duty workhorse. Its 43kW engine and 160 L/min hydraulic flow ensure productivity matches your primary units.
Equipped with a 0.30m³ backhoe bucket and generating 57kN bucket digging force, this excavator handles trenching, foundation prep, and utility work without bottlenecking crew schedules. Compact transport dimensions (6150×2230×2685mm) allow rapid repositioning between sites, while dual travel speeds (5.4/2.9 km/h) optimize efficiency across varied terrain.
- Maximum digging depth: 4020mm with 6260mm reach
- 130L fuel tank supports extended shifts without refueling delays
- 33.5 kPa ground pressure minimizes site disturbance
- Proven V2607 engine delivering 255.8 N·m maximum torque
Maintain project momentum when primary equipment undergoes scheduled maintenance. This unit keeps teams productive and contracts on schedule.
| Specifications | Value |
|---|---|
| No. | 1023626 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
