Product Description
Designed for precision and control, this 2022 XCMG XE75C mini excavator delivers reliable performance across demanding jobsites. Weighing 7,450 kg with a 0.30 m³ bucket capacity, this 7-ton machine combines compact dimensions with impressive reach—extending up to 6,260 mm maximum digging radius and 4,020 mm digging depth. Powered by a V2607 engine generating 43 kW at 2,000 rpm, operators benefit from consistent torque delivery and responsive hydraulics backed by a 160 l/min main pump flow.
Operator-Focused Features:
- Enhanced cabin visibility with 2,685 mm transport height for superior sightlines during grading and trenching operations
- Stable 33.5 kPa ground pressure minimizes surface disturbance while maintaining traction
- Smooth 10 rpm rotation speed enables precise positioning without jarring movements
- Dual travel speeds (5.4/2.9 km/h) provide flexibility between transit and controlled digging tasks
- Generous 130 L fuel tank and 115 L hydraulic reservoir support extended work shifts
Currently located in Guizhou, this Chinese-manufactured excavator offers proven XCMG engineering with straightforward maintenance access and dependable hydraulic per
| Specifications | Value |
|---|---|
| No. | 1023827 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
