Product Description
Engineered for precision work in confined spaces, this 7-ton excavator delivers exceptional operator control across demanding jobsites. With a 43kW rated power output and 255.8 N·m maximum torque, the V2607 engine provides consistent hydraulic performance through a 160 l/min main pump system. Operators benefit from enhanced visibility and ergonomic cabin design, enabling accurate bucket placement within a 6,260mm working radius and 4,020mm digging depth.
Stability remains paramount during rotation and excavation cycles. The 33.5 kPa ground pressure distributes the 7,450kg working weight effectively, while 57kN bucket digging force tackles compacted materials with authority. Dual travel speeds (5.4/2.9 km/h) optimize positioning efficiency on varied terrain.
- Maximum digging reach: 6,260mm with 7,085mm excavation height
- 0.30m³ backhoe bucket capacity for versatile material handling
- 10 rpm rotation speed ensures smooth, controlled operation
- 130L fuel tank supports extended work cycles
- Compact transport dimensions: 6,150mm (L) × 2,230mm (W) × 2,685mm (H)
Currently located in Yunnan, this 2023 XCMG XE75C represents proven Chinese manufacturing quality for contractor
| Specifications | Value |
|---|---|
| No. | 1023973 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
