Product Description
Built for the long haul, this 2024 XCMG XE75C excavator represents modern engineering excellence with a proven design legacy. Operating at 7 tons working weight with 7,450 kg of solid construction, this compact workhorse delivers exceptional durability for demanding job sites. Powered by a reliable V2607 engine producing 43 kW at 2,000 rpm and 255.8 N.m maximum torque, it combines robust performance with fuel efficiency from its 130-liter tank capacity.
Performance credentials include:
- Maximum digging depth of 4,020 mm with 6,260 mm reach
- Powerful 57 kN bucket digging force and 38 kN rod force
- 0.30 m³ backhoe bucket capacity for versatile material handling
- 160 L/min hydraulic flow ensuring responsive operation
- Compact transport dimensions: 6,150 mm × 2,230 mm × 2,685 mm
Currently located in Luzhou, Sichuan, this Made in China excavator demonstrates XCMG's commitment to building machines that withstand years of rigorous service. With low ground pressure of 33.5 kPa and proven reliability, it's engineered to be a dependable asset for infrastructure, construction, and earthmoving operations worldwide.
| Specifications | Value |
|---|---|
| No. | 1033910 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
