Product Description
Built for relentless performance, this 2025 XCMG XE75C mini excavator represents proven Chinese engineering at its finest. Operating at 7 tons with a working weight of 7,450 kg, this machine delivers consistent power through its v2607 engine, rated at 43 kW and 2000 rpm. Designed for demanding jobsites, it combines a 0.30 m³ bucket capacity with impressive digging force—57 kN bucket force and 38 kN rod force—ensuring productivity across excavation, trenching, and material handling applications.
Durability defines every component. With a 130L fuel tank and 115L hydraulic tank, extended operation periods minimize downtime. Maximum digging depth reaches 4,020 mm while maximum digging radius extends to 6,260 mm, providing versatile reach for confined urban sites or open terrain. Transport dimensions of 6,150 mm length by 2,230 mm width ensure easy mobilization between projects.
Currently located in Shenzhen, Guangdong, this workhorse offers:
- Maximum tractive force: 68.32 kN for challenging ground conditions
- Ground specific pressure: 33.5 kPa for reduced surface impact
- Dual travel speeds: 5.4/2.9 km/h for operational flexibility
- Maximum flow of 160 l/min from main pump
| Specifications | Value |
|---|---|
| No. | 1035809 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
