Product Description
Available now in Guangxi Nanning, this 2019 XCMG XE75DA mini excavator delivers 7-ton performance without factory wait times. Powered by a Yanmar V2607-DI-TE3B engine producing 42.4 kW at 2000 rpm, this compact workhorse combines 57 kN bucket digging force with a maximum digging depth of 4020 mm. Skip months of lead time and deploy this machine to your site immediately.
- Operating weight: 7,460 kg with 0.3 m³ bucket capacity
- Maximum digging radius of 6,260 mm and unloading height of 5,160 mm
- 160 L/min main pump flow for responsive hydraulic performance
- Compact transport dimensions: 6,150 mm (L) × 2,230 mm (W) × 2,685 mm (H)
- 70% climbing ability with 68.3 kN maximum tractive force
- Fast deployment from Guangxi region to your project location
Ready for immediate inspection and shipment. Eliminate procurement delays and keep your operations moving forward with this proven XCMG platform.
| Specifications | Value |
|---|---|
| No. | 1015509 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7460 |
| Bucket capacity (m³) | 0.3 |
| Boom length (mm) | 3720 |
| Rod length (mm) | 1622 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | V2607-DI-TE3B |
| Rated power (kw/rpm) | 42.4/2000 |
| Maximum torque (N.m) | 225.8 |
| Displacement (L) | 2.615 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.3 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 18.6 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 76 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Counterweight ground clearance (mm) | 815 |
| Minimum ground clearance (mm) | 380 |
| Minimum turning radius of front working device (mm) | 1818 |
| Back end turning radius (mm) | 1800 |
| Track gauge (mm) | 1750 |
| Track plate width (mm) | 450 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 5160 |
| Maximum vertical digging depth (mm) | 2920 |
