Product Description
With a working weight of 7460 kg and a bucket capacity of 0.3 m³, the XCMG XE75DA, manufactured in 2020, is a robust choice for your construction needs. Located in Jiangsu Xuzhou, this excavator boasts a V2607-DI-TE3B engine, delivering 42.4 kW at 2000 rpm, ensuring reliable performance on any job site. XCMG’s reputation for durability and easy maintenance makes it a preferred choice in the used market. Parts are readily available, and its strong resale value ensures a sound investment. The XE75DA offers a maximum digging depth of 4020 mm and a digging force of 57 kN, making it versatile for various applications. Trust XCMG for a machine that not only meets but exceeds expectations in reliability and performance.
- Working weight: 7460 kg
- Bucket capacity: 0.3 m³
- Engine: V2607-DI-TE3B, 42.4 kW at 2000 rpm
- Maximum digging depth: 4020 mm
- Digging force: 57 kN
| Specifications | Value |
|---|---|
| No. | 1023897 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7460 |
| Bucket capacity (m³) | 0.3 |
| Boom length (mm) | 3720 |
| Rod length (mm) | 1622 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | V2607-DI-TE3B |
| Rated power (kw/rpm) | 42.4/2000 |
| Maximum torque (N.m) | 225.8 |
| Displacement (L) | 2.615 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.3 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 18.6 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 76 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Counterweight ground clearance (mm) | 815 |
| Minimum ground clearance (mm) | 380 |
| Minimum turning radius of front working device (mm) | 1818 |
| Back end turning radius (mm) | 1800 |
| Track gauge (mm) | 1750 |
| Track plate width (mm) | 450 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 5160 |
| Maximum vertical digging depth (mm) | 2920 |
