Product Description
Built for relentless performance, this 2022 XCMG XE75DA excavator delivers proven reliability in a compact 7-ton package. Powered by a robust V2607-DI-TE3B engine generating 42.4kW at 2000rpm, this workhorse combines exceptional digging force with fuel-efficient operation. With only minimal operational hours since manufacture, this machine demonstrates XCMG's commitment to durability and engineering excellence.
- Operating weight: 7,460kg with 0.3m³ bucket capacity
- Maximum digging depth: 4,020mm; maximum reach: 6,260mm
- Bucket digging force: 57kN; arm digging force: 38kN
- Hydraulic system: 160L/min main pump flow, 28MPa working pressure
- Travel speed: 5.4km/h (high) / 2.9km/h (low)
- Impressive 70% climbing ability for challenging terrain
- 130L fuel tank and 76L hydraulic tank for extended operation
- Compact transport dimensions: 6,150mm × 2,230mm × 2,685mm
Currently located in Shaoxing, Zhejiang, this machine represents exceptional value for contractors seeking dependable performance without compromise. Factory-fresh condition with full specifications intact.
| Specifications | Value |
|---|---|
| No. | 1021114 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7460 |
| Bucket capacity (m³) | 0.3 |
| Boom length (mm) | 3720 |
| Rod length (mm) | 1622 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | V2607-DI-TE3B |
| Rated power (kw/rpm) | 42.4/2000 |
| Maximum torque (N.m) | 225.8 |
| Displacement (L) | 2.615 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.3 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 18.6 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 76 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Counterweight ground clearance (mm) | 815 |
| Minimum ground clearance (mm) | 380 |
| Minimum turning radius of front working device (mm) | 1818 |
| Back end turning radius (mm) | 1800 |
| Track gauge (mm) | 1750 |
| Track plate width (mm) | 450 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 5160 |
| Maximum vertical digging depth (mm) | 2920 |
