Product Description
Backed by China's largest construction machinery manufacturer, this 2016 XCMG XE80 excavator delivers proven 8-ton performance with the long-term support infrastructure serious buyers demand. Powered by a reliable Cummins B3.3 engine producing 60kW at 2200rpm, this compact workhorse combines a 6375mm maximum digging radius with 4140mm digging depth—ideal for urban construction, utility work, and landscaping projects.
XCMG's established global parts network ensures minimal downtime, while the brand's strong resale value protects your investment. Currently located in Chongqing, this unit features:
- Toshiba variable pump hydraulic system with 198 L/min flow capacity
- 53.6kN bucket digging force and 39.2kN arm digging force
- Water-cooled turbocharged 6-cylinder engine for consistent power delivery
- Compact transport dimensions (6155mm × 2220mm × 2610mm) for easy mobilization
- 35° climbing ability and 2.7-4.2 km/h travel speeds
With 7425kg working weight and 34.2kPa ground pressure, this machine balances stability with minimal surface impact. XCMG's reputation for durability and parts availability makes this XE80 a smart choice for contractors seeking dependable pre-owne
| Specifications | Value |
|---|---|
| No. | 1015360 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7425 |
| Bucket capacity (m³) | 0.14-0.34 |
| Boom length (mm) | 3710 |
| Rod length (mm) | 1650 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Cummins B3.3 |
| Rated power (kw/rpm) | 60/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 3.3 |
| Working form | Water cooled/turbocharged |
| Ground specific pressure (Kpa) | 34.2 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 53.6 |
| Rod digging force (kN) | 39.2 |
| Travel speed (km/h) | 4.2/2.7 |
| Main overflow set pressure (Mpa) | 27.4 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*198+21 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 20.6 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Toshiba variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 127 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 7 |
| Total transport length (mm) | 6155 |
| Total transport width (mm) | 2220 |
| Total transport height (mm) | 2610 |
| Counterweight ground clearance (mm) | 786 |
| Minimum ground clearance (mm) | 392 |
| Minimum turning radius of front working device (mm) | 1815 |
| Back end turning radius (mm) | 1770 |
| Track gauge (mm) | 1700 |
| Track plate width (mm) | 450 |
| Track ground length (mm) | 2119 |
| Maximum digging radius (mm) | 6375 |
| Maximum digging depth (mm) | 4140 |
| Maximum excavation height (mm) | 7167 |
| Maximum unloading height (mm) | 5100 |
| Maximum vertical digging depth (mm) | 3218 |
