Proven on job sites worldwide, this 2021 XCMG XE80 delivers the performance and dependability contractors demand in an 8-ton excavator. Powered by a reliable Cummins B3.3 engine generating 60kW at 2200rpm, this machine combines robust digging force (53.6kN bucket, 39.2kN arm) with precision hydraulics from a Toshiba variable pump system. Maximum digging depth reaches 4,140mm with an impressive 6,375mm working radius, making it ideal for utility work, foundation digging, and site preparation.
XCMG's market dominance translates directly into owner advantages: parts availability remains excellent across global markets, service networks are extensive, and resale values hold strong compared to lesser-known brands. Currently located in Wenzhou, Zhejiang, this unit features water-cooled turbocharged operation, plunger hydraulic motors for travel and rotation, and a 450mm track width providing 34.2kPa ground pressure for stability on varied terrain.
- Working Weight: 7,425kg with optimal 35° climbing capability
- Hydraulic Efficiency: 27.4MPa main system pressure, 198L/min flow
- Compact Transport: 6,155mm length × 2,220mm width
- Factory-Direct Xuzhou Manufacturing Quality
| Specifications | Value |
|---|---|
| No. | 1017354 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7425 |
| Bucket capacity (m³) | 0.14-0.34 |
| Boom length (mm) | 3710 |
| Rod length (mm) | 1650 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Cummins B3.3 |
| Rated power (kw/rpm) | 60/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 3.3 |
| Working form | Water cooled/turbocharged |
| Ground specific pressure (Kpa) | 34.2 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 53.6 |
| Rod digging force (kN) | 39.2 |
| Travel speed (km/h) | 4.2/2.7 |
| Main overflow set pressure (Mpa) | 27.4 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*198+21 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 20.6 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Toshiba variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 127 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 7 |
| Total transport length (mm) | 6155 |
| Total transport width (mm) | 2220 |
| Total transport height (mm) | 2610 |
| Counterweight ground clearance (mm) | 786 |
| Minimum ground clearance (mm) | 392 |
| Minimum turning radius of front working device (mm) | 1815 |
| Back end turning radius (mm) | 1770 |
| Track gauge (mm) | 1700 |
| Track plate width (mm) | 450 |
| Track ground length (mm) | 2119 |
| Maximum digging radius (mm) | 6375 |
| Maximum digging depth (mm) | 4140 |
| Maximum excavation height (mm) | 7167 |
| Maximum unloading height (mm) | 5100 |
| Maximum vertical digging depth (mm) | 3218 |
