Product Description
Featuring a robust design and reliable performance, the 2022 XCMG XE80 excavator stands as a testament to durability and engineering excellence. With a working weight of 7425 kg and an 8-ton capacity, this machine is powered by a Cummins B3.3 engine, delivering 60 kW at 2200 rpm. Its water-cooled, turbocharged system ensures efficient operation under various conditions.
- Built to last, the XE80 offers a bucket capacity ranging from 0.14 to 0.34 m³, ideal for diverse excavation tasks.
- Equipped with a plunger hydraulic motor and a Toshiba variable pump, it provides precise control and high efficiency.
- Proven in demanding environments, the XE80 boasts a maximum digging depth of 4140 mm and a maximum digging height of 7167 mm.
- Its 35° climbing ability and 4.2 km/h travel speed enhance maneuverability on challenging terrains.
Located in Hunan, this excavator is ready to tackle your next project with reliability and strength. Trust in the proven record of the XCMG XE80 for your heavy machinery needs.
| Specifications | Value |
|---|---|
| No. | 1002833 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7425 |
| Bucket capacity (m³) | 0.14-0.34 |
| Boom length (mm) | 3710 |
| Rod length (mm) | 1650 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Cummins B3.3 |
| Rated power (kw/rpm) | 60/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 3.3 |
| Working form | Water cooled/turbocharged |
| Ground specific pressure (Kpa) | 34.2 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 53.6 |
| Rod digging force (kN) | 39.2 |
| Travel speed (km/h) | 4.2/2.7 |
| Main overflow set pressure (Mpa) | 27.4 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*198+21 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 20.6 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Toshiba variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 127 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 7 |
| Total transport length (mm) | 6155 |
| Total transport width (mm) | 2220 |
| Total transport height (mm) | 2610 |
| Counterweight ground clearance (mm) | 786 |
| Minimum ground clearance (mm) | 392 |
| Minimum turning radius of front working device (mm) | 1815 |
| Back end turning radius (mm) | 1770 |
| Track gauge (mm) | 1700 |
| Track plate width (mm) | 450 |
| Track ground length (mm) | 2119 |
| Maximum digging radius (mm) | 6375 |
| Maximum digging depth (mm) | 4140 |
| Maximum excavation height (mm) | 7167 |
| Maximum unloading height (mm) | 5100 |
| Maximum vertical digging depth (mm) | 3218 |
