Product Description
Built for demanding jobsites, this 8-ton excavator delivers proven performance backed by XCMG's established manufacturing reputation. Operating at 7,425 kg working weight, the XE80 combines a Cummins B3.3 engine (60 kW at 2200 rpm) with Toshiba variable pump hydraulics, providing 53.6 kN bucket digging force and 39.2 kN rod digging force. With a maximum digging depth of 4,140 mm and reach extending to 6,375 mm, this machine handles diverse excavation requirements efficiently.
XCMG's market dominance translates directly into ownership advantages. Parts availability across China remains exceptional, minimizing downtime and reducing operational costs. Resale values hold strong due to widespread dealer networks and technician familiarity with XCMG systems. The XE80's water-cooled, turbocharged 6-cylinder configuration ensures durability, while standard features including plunger hydraulic motors for rotation and travel demonstrate engineering quality that protects your investment.
Currently located in Gansu, this 2025 model represents a strategic acquisition for contractors prioritizing long-term reliability over experimental alternatives. Track dimensions of 2,119 mm ground length and 450 mm width provide 34.2 kPa groun
| Specifications | Value |
|---|---|
| No. | 1010744 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7425 |
| Bucket capacity (m³) | 0.14-0.34 |
| Boom length (mm) | 3710 |
| Rod length (mm) | 1650 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Cummins B3.3 |
| Rated power (kw/rpm) | 60/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 3.3 |
| Working form | Water cooled/turbocharged |
| Ground specific pressure (Kpa) | 34.2 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 53.6 |
| Rod digging force (kN) | 39.2 |
| Travel speed (km/h) | 4.2/2.7 |
| Main overflow set pressure (Mpa) | 27.4 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*198+21 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 20.6 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Toshiba variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 127 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 7 |
| Total transport length (mm) | 6155 |
| Total transport width (mm) | 2220 |
| Total transport height (mm) | 2610 |
| Counterweight ground clearance (mm) | 786 |
| Minimum ground clearance (mm) | 392 |
| Minimum turning radius of front working device (mm) | 1815 |
| Back end turning radius (mm) | 1770 |
| Track gauge (mm) | 1700 |
| Track plate width (mm) | 450 |
| Track ground length (mm) | 2119 |
| Maximum digging radius (mm) | 6375 |
| Maximum digging depth (mm) | 4140 |
| Maximum excavation height (mm) | 7167 |
| Maximum unloading height (mm) | 5100 |
| Maximum vertical digging depth (mm) | 3218 |
