Product Description
Backed by China's largest construction machinery manufacturer, this 2012 XCMG XE85C 8-ton excavator delivers proven reliability for mid-sized earthmoving operations. Powered by a robust 4JG1TPC engine producing 53.8kW at 2150rpm, this compact workhorse combines a 6295mm maximum digging radius with 4130mm digging depth—ideal for utility work, trenching, and site preparation across demanding jobsites.
XCMG's global parts network ensures minimal downtime, while the brand's strong resale value protects your investment long-term. Currently located in Hunan, China, this machine features:
- 0.34m³ bucket capacity with 51.2kN digging force
- 7700kg operating weight with integrated dozer blade
- 198+21 L/min hydraulic flow for responsive performance
- Compact 2332mm transport width for easy mobilization
- 35° climbing ability and 11rpm rotation speed
With over a decade of field-proven service and XCMG's reputation for durability, this XE85C offers dependable performance at a competitive price point. Parts availability and technical support remain excellent throughout Asia, Africa, and emerging markets where XCMG maintains dominant market share.
| Specifications | Value |
|---|---|
| No. | 1027595 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7700/8100 (with dozer) |
| Bucket capacity (m³) | 0.34 |
| Boom length (mm) | 3720 |
| Rod length (mm) | 1622 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4JG1TPC |
| Rated power (kw/rpm) | 53.8/2150 |
| Maximum torque (N.m/rpm) | 255/1800 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Ground specific pressure (Kpa) | 34.6/36.4 (with dozer) |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 51.2 |
| Rod digging force (kN) | 34.2 |
| Maximum tractive force (kN) | 34.2 |
| Travel speed (km/h) | 4.9/2.6 |
| Maximum flow of main pump (l/min) | 198+21 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 20.6 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 9.7 |
| Total transport length (mm) | 6144 |
| Total transport width (mm) | 2332 |
| Total transport height (mm) | 2712 |
| Counterweight ground clearance (mm) | 827 |
| Minimum ground clearance (mm) | 428 |
| Back end turning radius (mm) | 1805 |
| Track gauge (mm) | 1870 |
| Total track width (mm) | 450 |
| Maximum digging radius (mm) | 6295 |
| Maximum digging depth (mm) | 4130 |
| Maximum excavation height (mm) | 7165 |
| Maximum unloading height (mm) | 5060 |
| Maximum vertical digging depth (mm) | 3500 |
| Bulldozer lift or depth (mm) | 409/438 |
| Dodging plate width × height (mm) | 2320 x 416 |
