Product Description
Engineered for relentless performance, this 2024 XCMG XE85C 8-ton excavator represents modern reliability in compact earthmoving machinery. Powered by a robust 4JG1TPC engine delivering 53.8 kW at 2150 rpm, this machine combines proven hydraulic efficiency with exceptional digging force—51.2 kN bucket force and 34.2 kN arm force tackle demanding excavation tasks with consistent precision. Operating weight of 8,100 kg with dozer blade provides optimal stability across varied terrain conditions.
Built to withstand rigorous job site demands, this workhorse features a maximum digging reach of 6,295 mm and depth capacity of 4,130 mm, making it ideal for utility work, foundation projects, and material handling. Current location in Shenzhen, Guangdong positions this unit for immediate deployment across Southeast Asian markets.
- Bucket Capacity: 0.34 m³ backhoe configuration
- Hydraulic System: 198+21 L/min main pump flow
- Fuel Efficiency: 130 L tank for extended operation
- Compact Transport: 6,144 mm × 2,332 mm × 2,712 mm
- Climbing Ability: 35° gradient capability
- Manufacturer: XCMG, China—proven industrial heritage
| Specifications | Value |
|---|---|
| No. | 1026960 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7700/8100 (with dozer) |
| Bucket capacity (m³) | 0.34 |
| Boom length (mm) | 3720 |
| Rod length (mm) | 1622 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4JG1TPC |
| Rated power (kw/rpm) | 53.8/2150 |
| Maximum torque (N.m/rpm) | 255/1800 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Ground specific pressure (Kpa) | 34.6/36.4 (with dozer) |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 51.2 |
| Rod digging force (kN) | 34.2 |
| Maximum tractive force (kN) | 34.2 |
| Travel speed (km/h) | 4.9/2.6 |
| Maximum flow of main pump (l/min) | 198+21 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 20.6 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 9.7 |
| Total transport length (mm) | 6144 |
| Total transport width (mm) | 2332 |
| Total transport height (mm) | 2712 |
| Counterweight ground clearance (mm) | 827 |
| Minimum ground clearance (mm) | 428 |
| Back end turning radius (mm) | 1805 |
| Track gauge (mm) | 1870 |
| Total track width (mm) | 450 |
| Maximum digging radius (mm) | 6295 |
| Maximum digging depth (mm) | 4130 |
| Maximum excavation height (mm) | 7165 |
| Maximum unloading height (mm) | 5060 |
| Maximum vertical digging depth (mm) | 3500 |
| Bulldozer lift or depth (mm) | 409/438 |
| Dodging plate width × height (mm) | 2320 x 416 |
