Product Description
Backed by China's largest construction machinery manufacturer, this 2020 XCMG XE900C excavator delivers 90-ton class performance with the reliability that keeps global fleets running. Powered by a Cummins QSX15 engine producing 395kW at 1800rpm, this machine combines proven Western powertrain technology with XCMG's robust hydraulics—twin 521 L/min plunger pumps driving 480kN bucket digging force and a 12,330mm maximum reach. Currently located in Luzhou, Sichuan, it offers 4.0-5.0m³ bucket capacity and maintains just 131kPa ground pressure despite its 88-tonne operating weight.
XCMG's dominant market position translates directly into ownership advantages: parts distribution networks span six continents, authorized service centers stock critical components, and strong resale values protect your investment. The brand's 30+ year mining heritage means this XE900C shares components with thousands of sister machines worldwide. Water-cooled turbocharged operation, 755L hydraulic reservoir, and 7.3rpm swing speed ensure productivity matches durability. For contractors requiring proven capacity without the premium of European brands, this excavator represents strategic value—XCMG's scale ensures you'll never wait weeks for parts or st
| Specifications | Value |
|---|---|
| No. | 1023627 |
| Tonnage (tons) | 90 |
| Working weight (kg) | 88000 |
| Bucket capacity (m³) | 4.0-5.0 |
| Boom length (mm) | 7100 |
| Rod length (mm) | 2945 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | CUMMINS QSX15 |
| Rated power (kw/rpm) | 395/1800 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 15 |
| Working form | Turbocharged/air-to-air cooling |
| Ground specific pressure (Kpa) | 131 |
| Rotation speed (rpm) | 7.3 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 480 |
| Rod digging force (kN) | 370 |
| Travel speed (km/h) | 3.9/2.7 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*521 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 30 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 1225 |
| Hydraulic Tank (L) | 755 |
| Engine Oil changes (L) | 48 |
| Total transport length (mm) | 13570 |
| Total transport width (mm) | 4550 |
| Total transport height (mm) | 5090 |
| Full cab height (mm) | 1680 |
| Minimum ground clearance (mm) | 880 |
| Minimum turning radius of front working device (mm) | 5200 |
| Back end turning radius (mm) | 4700 |
| Track gauge (mm) | 2960/3500 |
| Track plate width (mm) | 650 |
| Track ground length (mm) | 4545 |
| Maximum digging radius (mm) | 12330 |
| Maximum digging depth (mm) | 7250 |
| Maximum excavation height (mm) | 12060 |
| Maximum unloading height (mm) | 8070 |
| Maximum vertical digging depth (mm) | 4200 |
