Product Description
Maximize your construction budget with this 2024 XCMG ZL50G wheel loader, delivering exceptional value without compromising performance. Built for demanding jobsites, this machine combines a powerful 162kW engine with a substantial 3m³ bucket capacity and 5-ton rated load capability.
Key specifications include:
- 170kN digging force for challenging material handling
- 18,000kg operating weight ensures stability during heavy operations
- 3,090mm unloading height with 1,130mm reach at 45° angle
- Maximum climbing ability of 28° tackles steep terrain
- Dual-speed transmission: 11.5-16.5 km/h (1st gear), 37 km/h (2nd gear)
- 6,400mm turning radius for maneuverability in tight spaces
Located in Luzhou, Sichuan, this ZL50G represents smart capital allocation—delivering proven XCMG reliability and robust performance at a fraction of new equipment costs. With rapid 6-second lift cycles and 11-second combined operations, productivity remains uncompromised while your bottom line benefits significantly.
| Specifications | Value |
|---|---|
| No. | 991893 |
| Engine type | |
| Rated power (kw/rpm) | 162/2200 |
| Bucket capacity (m³) | 3 |
| Rated load (tons) | |
| Rated load (kg) | 5000 |
| Digging force (lifting force) (kN) | 170 |
| Machine operating weight (kg) | 18000 |
| Unloading height - Unloading Angle 45°(mm) | 3090 |
| Unloading distance - Unloading Angle 45°(mm) | 1130 |
| Maximum tractive force (kN) | 145 |
| Maximum climbing ability (°) | 28 |
| Wheelbase (mm) | 3300 |
| Wheel base (mm) | 2200 |
| Machine length (mm) | 8110 |
| Machine width (mm) | 3000 |
| Machine height (mm) | 3460 |
| Minimum turning radius of outer wheel center line | 6400 |
| Lift (s) | 6 |
| Ternary sum (s) | 11 |
| Speed 1 gear (km/h) | 11.5/16.5 |
| Speed 2 (km/h) | 37 |
