Product Description
Power through high-volume material handling operations with this 2024 XCMG ZL60G wheel loader, currently positioned in Kunming, Yunnan. Built around a 174kW engine and 6-ton rated load capacity, this machine delivers consistent performance across loading, stockpiling, and truck-filling applications. The 3.3m³ bucket moves material efficiently while the 165kN maximum tractive force ensures solid traction in challenging ground conditions.
Operational specifications include a 3,100mm unloading height at 45° and 12-second total cycle time, supporting rapid load-and-dump sequences that keep production moving. With an operating weight of 20,500kg and 28° maximum climbing capability, this loader handles grade work and uneven terrain without hesitation. Four forward speeds reach up to 36km/h for quick repositioning between work zones.
- 174kW rated power at 2,200rpm
- 6,000kg rated load capacity
- 3.3m³ bucket capacity
- 6.5-second lift time
- 3,400mm wheelbase for stability
- 6,495mm minimum turning radius
Site-ready for quarries, construction yards, and material transfer operations requiring dependable loading capacity.
| Specifications | Value |
|---|---|
| No. | 1018206 |
| Engine type | |
| Rated power (kw/rpm) | 174/2200 |
| Bucket capacity (m³) | 3.3 |
| Rated load (tons) | |
| Rated load (kg) | 6000 |
| Machine operating weight (kg) | 20500 |
| Unloading height - Unloading Angle 45°(mm) | 3100 |
| Unloading distance - Unloading Angle 45°(mm) | 1250 |
| Maximum tractive force (kN) | 165 |
| Maximum climbing ability (°) | 28 |
| Wheelbase (mm) | 3400 |
| Wheel base (mm) | 2200 |
| Machine length (mm) | 8593 |
| Machine width (mm) | 3050 |
| Machine height (mm) | 3435 |
| Minimum turning radius of outer wheel center line | 6495 |
| Lift (s) | 6.5 |
| Ternary sum (s) | 12 |
| Speed 1 gear (km/h) | 6 |
| Speed 2 (km/h) | 11 |
| Speed 3 (km/h) | 23 |
| Speed 4 (km/h) | 36 |
