2024 Caterpillar 301.7CR






Product Description
This 2024 Caterpillar 301.7CR mini excavator represents excellent value in the compact equipment segment. Currently located in Ningxia, China, this machine features low operating hours and demonstrates strong performance characteristics typical of late-model Caterpillar equipment.
Key highlights include:
- 2024 model year with minimal operational hours
- Robust engine performance with verified maintenance history
- Responsive hydraulic controls for precise operation
- Compact radius design ideal for confined work areas
- Genuine hour meter reading, no discrepancies
- Well-maintained mechanical condition throughout
The Cat 301.7CR is renowned for its maneuverability in tight spaces while delivering reliable digging performance. This unit is available for immediate inspection and pricing is negotiable for qualified buyers. Suitable for contractors requiring dependable mini excavator capacity for utility work, landscaping, and light construction applications.
| Specifications | Value |
|---|---|
| No. | 1138739 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1690.0 |
| Bucket capacity (m³) | 0.02-0.04 |
| Rod length (mm) | 940.0 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 3 tnv76 |
| Rated power (kw/rpm) | 13.2/2200 |
| Climbing ability (%) | 58 |
| Bucket digging force (kN) | 14.2 kN |
| Rod digging force (kN) | 8.4 kN |
| Travel speed (km/h) | 2.8-5.6 |
| Maximum flow of main pump (l/min) | 39.6 L/min |
| Traveling Hydraulic Circuit (Mpa) | 240.0 ba |
| Rotary Hydraulic Circuit (Mpa) | 180.0 bar |
| Working Hydraulic Circuit (Mpa) | 240.0 bar |
| Fuel Tank (L) | 19.0 |
| Hydraulic Tank (L) | 20.0 |
| Total transport length (mm) | 3584.0 |
| Total transport width (mm) | 1300.0 |
| Back end turning radius (mm) | 660 |
| Track ground length (mm) | 1607.0 |
| Maximum digging depth (mm) | 2321.0 |
| Maximum excavation height (mm) | 3434.0 |
| Maximum unloading height (mm) | 2441.0 |
| Maximum vertical digging depth (mm) | 1578.0 |
| Bulldozer lift or depth (mm) | 271.0 mm*390.0 mm |
| Dodging plate width × height (mm) | 990 *230.0 mm |
| Maximum excavation radius of stop surface (mm) | 3842.0 |
Overview
No.1138739
Brand Name:
CaterpillarModel Number:
301.7CR
Year:
2024
Location:
Ningxia China
Pub Date:
