Product Description
Maximize your equipment budget with this 2016 Sumitomo SH80-6 excavator from Hubei—delivering proven 8-ton performance at a fraction of new equipment costs. Powered by a reliable Isuzu AU-4LE2X engine producing 40kW at 2000 rpm, this compact workhorse combines Japanese engineering with exceptional value retention. At 7,460 kg working weight and a 0.38 m³ bucket capacity, it tackles demanding jobsites while maintaining a competitive operating footprint of just 2,320 mm width.
- Maximum Reach: 6,460 mm digging radius with 4,050 mm depth capability
- Robust Power: 56.4 kN bucket digging force and 39.3 kN rod digging force
- Efficient Operation: 120L fuel tank, 29.4 MPa hydraulic system, 5.1 km/h travel speed
- Compact Mobility: 1,750 mm rear turning radius for confined work areas
- Smart Investment: Joint venture quality with proven 1,690 mm rod length for versatile applications
Secure high-performance excavation capability without the premium price tag. This well-maintained unit offers immediate deployment potential for contractors seeking reliable productivity and superior ROI.
| Specifications | Value |
|---|---|
| No. | 1030162 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7460 |
| Bucket capacity (m³) | 0.38 |
| Rod length (mm) | 1690 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu AU-4LE2X |
| Rated power (kw/rpm) | 40/2000 |
| Displacement (L) | 2.179 |
| Rotation speed (rpm) | 9.9 |
| Climbing ability (%) | |
| Bucket digging force (kN) | 56.4 |
| Rod digging force (kN) | 39.3 |
| Travel speed (km/h) | 5.1/3.2 |
| Main overflow set pressure (Mpa) | 29.4 |
| Type of walking hydraulic motor | |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 51 |
| Hydraulic System (L) | 96 |
| Total transport length (mm) | 6090 |
| Total transport width (mm) | 2320 |
| Total transport height (mm) | 2750 |
| Counterweight ground clearance (mm) | 750 |
| Minimum turning radius of front working device (mm) | 1980 |
| Back end turning radius (mm) | 1750 |
| Total track length (mm) | 2845 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2320 |
| Track ground length (mm) | 2210 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4050 |
| Maximum excavation height (mm) | 6950 |
| Maximum unloading height (mm) | 4890 |
