Product Description
This 2020 Sany SY195C hydraulic excavator represents a reliable mid-size solution for diverse earthmoving applications. Currently located in Fujian, China, this machine offers proven performance from one of the industry's leading manufacturers. The SY195C is engineered for operational efficiency in construction, demolition, and material handling projects.
Key attributes include:
- Operating weight class suitable for medium-duty excavation tasks
- Fuel-efficient engine designed for extended worksite productivity
- Robust hydraulic system delivering consistent digging and lifting performance
- Spacious operator cabin with ergonomic controls
- Durable undercarriage built for varied terrain conditions
This locally available unit provides an opportunity to acquire quality used equipment from Sany's established excavator lineup. Suitable for contractors and operators seeking dependable machinery with proven field performance.
| Specifications | Value |
|---|---|
| No. | 1120229 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
