2018 Caterpillar 313D
Product Description
Positioned in Xuzhou, Jiangsu—China's heavy equipment hub—this 2018 Caterpillar 313D is available now for immediate deployment. Skip factory lead times and accelerate your project timeline with a proven 13-ton excavator ready to ship directly to your site. Powered by the reliable Cat C4.2 ACERT engine delivering 67 kW, this machine combines robust digging performance with fuel-efficient operation compliant with US EPA Tier 3 and EU Stage IIIA standards.
- Working Weight: 13,430 kg with 0.52 m³ bucket capacity
- Digging Reach: 8,220 mm maximum excavation radius, 5,580 mm max depth
- Hydraulic Power: 127 L/min main pump flow, 82 kN bucket digging force
- Transport Dimensions: 7,610 × 2,490 × 2,830 mm for container-friendly shipping
- Strategic Location: Xuzhou logistics networks enable rapid global export
Engineered for versatility across construction, demolition, and earthmoving applications, this joint-venture manufactured unit offers OEM-grade reliability at used equipment value. Secure your operational advantage with same-week logistics coordination from Jiangsu Province.
| Specifications | Value |
|---|---|
| No. | 1025555 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13430 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4650 |
| Rod length (mm) | 2500 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C4.2 ACERT |
| Rated power (kw/rpm) | 67 (Net power) |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.25 |
| Working form | Meets the emission requirements of US EPA Tier 3 and European IIIA Directive 97/68/EC. |
| Ground specific pressure (Kpa) | 41.8 (with 500mm track plate) |
| Rotation speed (rpm) | 12.4 |
| Bucket digging force (kN) | 82 |
| Rod digging force (kN) | 63 |
| Maximum tractive force (kN) | 114 |
| Travel speed (km/h) | 5.5 |
| Main overflow set pressure (Mpa) | 30.5 |
| Maximum flow of main pump (l/min) | 127 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Pilot Oil Circuit (MPa) | 41.2 |
| Pilot pump flow (L/min) | 21.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 100 x 939 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 120 x 1197 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 110 x 1015 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 19.5 |
| Coolant (L) | 17.9 |
| Hydraulic System (L) | 162 (including fuel tank) |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2830 (to top of boom) |
| Full cab height (mm) | 2760 |
| Counterweight ground clearance (mm) | 915 |
| Minimum ground clearance (mm) | 430 |
| Back end turning radius (mm) | 2140 |
| Total track length (mm) | 3490 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 (standard) |
| Total track width (mm) | 2490 |
| Maximum digging depth (mm) | 5580 |
| Maximum unloading height (mm) | 6060 |
| Maximum vertical digging depth (mm) | 5040 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 8220 |
| Boom turning Angle (left/right °) | There is no |
| Maximum effective digging depth (mm) | 5380 |
Overview
No.1025555
Brand Name：
CaterpillarModel Number：
313DYear：
2018
Location：
Jiangsu China
Pub Date：
