2020 Caterpillar 320CL
Product Description
Discover the reliability and performance of the 2020 Caterpillar 320CL, now available in Guangdong, China. This used excavator, with over 70,000 hours of operation, has been a staple in demanding construction environments, showcasing its durability and efficiency. Ideal for a wide range of applications, this machine is equipped with a large capacity cooling system, ensuring optimal performance even in high-temperature conditions. The 320CL is ready to meet your project needs, offering robust construction, ease of maintenance, and the trusted Caterpillar brand assurance. Consider this well-maintained unit for your fleet to enhance productivity and reduce downtime.
- Year: 2020
- Brand: Caterpillar
- Model: 320CL
- Operating Hours: Over 70,000
- Location: Guangdong, China
| Specifications | Value |
|---|---|
| No. | 1165273 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21415 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2900 |
| Country of origin | Xuzhou/Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar CAT 3066ATAAC |
| Rated power (kw/rpm) | 110/1800 |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Displacement (L) | 6.4 |
| Ground specific pressure (Kpa) | 44.1 |
| Rotation speed (rpm) | 11.5 |
| Bucket digging force (kN) | 132 |
| Rod digging force (kN) | 99 |
| Travel speed (km/h) | 3.4/5.5 |
| Maximum flow of main pump (l/min) | 205 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 26 |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1030 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1430 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 1260 |
| Fuel Tank (L) | 320 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 200 |
| Total transport length (mm) | 9390 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3050 |
| Full cab height (mm) | 3050 |
| Minimum ground clearance (mm) | 460 |
| Back end turning radius (mm) | 2770 |
| Total track length (mm) | 4450 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2980 |
| Track ground length (mm) | 3650 |
| Maximum digging depth (mm) | 6550 |
| Maximum excavation height (mm) | 9440 |
| Maximum unloading height (mm) | 6670 |
| Maximum vertical digging depth (mm) | 5440 |
| Maximum excavation radius of stop surface (mm) | 9710 |
| Maximum effective digging depth (mm) | 6370 |
Overview
No.1165273
Brand Name：
CaterpillarModel Number：
320CLYear：
2020
Location：
Guangdong China
Pub Date：
