2021 Caterpillar 320EL
Product Description
This 2021 Caterpillar 320EL hydraulic excavator represents a reliable solution for medium to heavy-duty earthmoving applications. As an officially imported unit with customs documentation, this machine offers the proven performance and durability that Caterpillar equipment is known for worldwide. Currently located in Shandong, China, this excavator is well-suited for construction, demolition, and material handling operations.
The 320EL combines operational efficiency with robust construction, featuring Caterpillar's dependable hydraulic systems and operator-focused design. With minimal operating hours for a 2021 model year, this excavator provides an excellent opportunity for contractors seeking quality used equipment with substantial service life remaining.
- Year of Manufacture: 2021
- Manufacturer: Caterpillar
- Model: 320EL
- Current Location: Shandong, China
- Import Status: Original customs-cleared import
| Specifications | Value |
|---|---|
| No. | 1077644 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500-24730 |
| Bucket capacity (m³) | 1.19 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 3900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C6.6 ACERT |
| Rated power (kw/rpm) | 114 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 105 x 127 |
| Number of cylinders (PCS) | 6 |
| Working form | Air to air cold; EPA Tier 4 emission standards |
| Ground specific pressure (Kpa) | 35 |
| Rotation speed (rpm) | 11.2 |
| Bucket digging force (kN) | 140.5 |
| Rod digging force (kN) | 89.7 |
| Maximum tractive force (kN) | 205 |
| Travel speed (km/h) | 5.6 |
| Turning torque (Nm) | 61.8 |
| Maximum flow of main pump (l/min) | 428 |
| Pilot Oil Circuit (MPa) | 3.92 |
| Pilot pump flow (L/min) | 24.3 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1104 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1504 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 1260 |
| Fuel Tank (L) | 410 |
| Hydraulic Tank (L) | 143 |
| Engine Oil changes (L) | 23 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 260 |
| Total transport length (mm) | 9340 |
| Total transport width (mm) | 2980/3170 |
| Total transport height (mm) | 3740 |
| Full cab height (mm) | 2960 |
| Counterweight ground clearance (mm) | 1020 |
| Minimum ground clearance (mm) | 450 |
| Back end turning radius (mm) | 2830 |
| Total track length (mm) | 4460 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600/700 |
| Total track width (mm) | 2980/3170 |
| Track ground length (mm) | 3650 |
| Maximum digging depth (mm) | 7580 |
| Maximum excavation height (mm) | 9890 |
| Maximum unloading height (mm) | 7030 |
| Maximum vertical digging depth (mm) | 6910 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 10680 |
| Boom turning Angle (left/right °) | There is no |
| Boom offset (left/right °) | There is no |
| Maximum effective digging depth (mm) | 7440 |
Overview
No.1077644
Brand Name：
CaterpillarModel Number：
320ELYear：
2021
Location：
Shandong China
Pub Date：
