2020 Caterpillar 324D

1/7

Product Description

Discover the exceptional quality of this 2020 Caterpillar 324D, available for immediate acquisition in Ningxia, China. Renowned for its robust construction and reliability, this machine is a prime choice for heavy-duty applications. The 324D has been meticulously maintained, ensuring it remains in top condition with no leaks, reflecting its solid build and durability. Ideal for professionals who recognize and value high performance and efficiency, this excavator is ready to meet the demands of your next project.

Year: 2020
Brand: Caterpillar
Model: 324D
Location: Ningxia, China

Specifications	Value
No.	1165260
Tonnage (tons)	24
Working weight (kg)	24240
Bucket capacity (m³)	1
Boom length (mm)	5900
Rod length (mm)	2950
Country of origin	Japan
power	Traditional power
manufacturer	Joint venture/Import
bucket	backhoe
Engine type	C7 ACERT
Rated power (kw/rpm)	140/2000
Cooling mode	water-cooling
Cylinder diameter × stroke (mm)	102 x 130
Number of cylinders (PCS)	6
Displacement (L)	7.2
Rotation speed (rpm)	9.6
Climbing ability (%)	70/35 °
Travel speed (km/h)	3.5/5.5
Main overflow set pressure (Mpa)	35
Maximum flow of main pump (l/min)	235
Traveling Hydraulic Circuit (Mpa)	35
Rotary Hydraulic Circuit (Mpa)	24.5
Hydraulic crushing pipeline is standard	no
Working Hydraulic Circuit (Mpa)	35
Pilot Oil Circuit (MPa)	3.9
Bucket cylinders - Number × diameter × stroke (mm)	1-120 x 1104
Bucket rod cylinders - Number × diameter × stroke (mm)	1-140 x 1660
Boom cylinders - Number × diameter × stroke (mm)	2-135 x 1305
Fuel Tank (L)	520
Hydraulic Tank (L)	145
Engine Oil changes (L)	30
Coolant (L)	30
Hydraulic System (L)	300(including fuel tank)
Total transport length (mm)	10060
Total transport width (mm)	2990
Total transport height (mm)	3170
Full cab height (mm)	2980
Counterweight ground clearance (mm)	1060
Minimum ground clearance (mm)	470
Back end turning radius (mm)	2940
Total track length (mm)	4250
Track gauge (mm)	2380
Track plate width (mm)	600
Total track width (mm)	2990
Track ground length (mm)	3450
Maximum digging depth (mm)	6740
Maximum excavation height (mm)	9660
Maximum unloading height (mm)	6700
Maximum vertical digging depth (mm)	5830
Bulldozer lift or depth (mm)	No bulldozer
Dodging plate width × height (mm)	No bulldozer
Maximum excavation radius of stop surface (mm)	10030
Maximum effective digging depth (mm)	6560
