2014 Caterpillar 326DL








Product Description
Investing in proven machinery means choosing a brand that stands behind its equipment long after the sale. This 2014 326DL excavator from Caterpillar delivers exactly that confidence, combining a robust 26-ton operating capacity with the legendary durability operators worldwide depend on. Powered by the Caterpillar C7 ACERT engine producing 140 kW, this machine offers reliable performance backed by an extensive global parts network that keeps downtime minimal and resale values strong.
Currently located in Shaoxing, Zhejiang, this excavator features:
- Bucket capacity of 1.35/1.57 m³ for versatile material handling
- Maximum digging depth of 6,740 mm with 10,030 mm reach
- Powerful digging forces: 174 kN bucket, 122 kN stick
- Water-cooled 7.2L displacement engine for consistent operation
- 520L fuel capacity supporting extended work cycles
Caterpillar's reputation translates directly into lower ownership costs. Parts availability remains exceptional even for older models, and certified technicians service these machines across China. When it's time to upgrade, Cat equipment consistently commands premium resale prices—a testament to build quality that buyers recognize and
| Specifications | Value |
|---|---|
| No. | 1006133 |
| Tonnage (tons) | 26 |
| Working weight (kg) | 25560 |
| Bucket capacity (m³) | 1.35/1.57 |
| Boom length (mm) | 5300/5900 |
| Rod length (mm) | 2000/2500/2950 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C7 ACERT |
| Rated power (kw/rpm) | 140 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 9.6 |
| Bucket digging force (kN) | 174 |
| Rod digging force (kN) | 122 |
| Maximum tractive force (kN) | 227 |
| Travel speed (km/h) | 5.5 |
| Turning torque (Nm) | 73.4 |
| Main overflow set pressure (Mpa) | 35 |
| Rotary hydraulic motor type | 24.5 |
| Type of walking hydraulic motor | 35 |
| Maximum flow of main pump (l/min) | 235 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 150 x 1156 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 140 x 1660 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 135 x 1305 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 300 |
| Total transport length (mm) | 10060 |
| Total transport width (mm) | 3390 |
| Total transport height (mm) | 3170 |
| Full cab height (mm) | 2980 |
| Counterweight ground clearance (mm) | 1060 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 2940 |
| Total track length (mm) | 4630 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3390 |
| Maximum digging depth (mm) | 6740 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 5830 |
| Maximum excavation radius of stop surface (mm) | 10030 |
| Maximum effective digging depth (mm) | 6560 |
Overview
No.1006133
Brand Name:
CaterpillarModel Number:
326DLYear:
2014
Location:
Zhejiang China
Pub Date:
