2016 Caterpillar 329DL
Product Description
Powered by the robust C7 ACERT engine delivering 152 kW at 2000 rpm, this 2016 Caterpillar 329DL excavator represents exceptional value for operators seeking proven performance without new equipment premiums. Operating at 29 tons with a 1.1 m³ bucket capacity, this Japanese-manufactured machine handles demanding excavation tasks with a maximum digging depth of 7,170 mm and reach extending to 10,600 mm. Water-cooled reliability combines with a 235 L/min hydraulic flow system engineered for consistent productivity across construction, mining, and infrastructure projects.
Key specifications include:
- 29,240 kg working weight with 6,150 mm boom and 3,200 mm arm configuration
- 7.2L displacement, 6-cylinder engine with 520L fuel capacity for extended operation
- 70% gradeability and dual travel speeds (3.5/5.3 km/h) for site versatility
- 3,990 mm track ground length with 800 mm plates ensuring superior stability
- Currently located in Zhanjiang, Guangdong for immediate inspection
Acquire proven Caterpillar engineering at a fraction of new equipment costs while maintaining the performance standards your operations demand.
| Specifications | Value |
|---|---|
| No. | 1017345 |
| Tonnage (tons) | 29 |
| Working weight (kg) | 29240 |
| Bucket capacity (m³) | 1.1 |
| Boom length (mm) | 6150 |
| Rod length (mm) | 3200 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C7ACERT |
| Rated power (kw/rpm) | 152/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 10.2 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 3.5/5.3 |
| Main overflow set pressure (Mpa) | 3.5 |
| Maximum flow of main pump (l/min) | 235 |
| Traveling Hydraulic Circuit (Mpa) | 3.5 |
| Rotary Hydraulic Circuit (Mpa) | 2.75 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 3.5 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 135 x 1156 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 150 x 1646 |
| Boom cylinders - Number × diameter × stroke (mm) | 140 x 1407 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 310(including fuel tank) |
| Total transport length (mm) | 10410 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3180 |
| Full cab height (mm) | 3040 |
| Counterweight ground clearance (mm) | 1110 |
| Minimum ground clearance (mm) | 490 |
| Back end turning radius (mm) | 3080 |
| Total track length (mm) | 4860 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 800 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 3990 |
| Maximum digging depth (mm) | 7170 |
| Maximum excavation height (mm) | 9990 |
| Maximum unloading height (mm) | 7020 |
| Maximum vertical digging depth (mm) | 6510 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10600 |
| Maximum effective digging depth (mm) | 7010 |
Overview
No.1017345
Brand Name：
CaterpillarModel Number：
329DLYear：
2016
Location：
Guangdong China
