2017 Caterpillar 330B





Product Description
With a robust 30-ton capacity and a powerful Caterpillar 3306TA engine, this 2017 Caterpillar 330B excavator is an ideal addition to any busy contractor's fleet. Featuring a 1.5 m³ bucket capacity and a 6500 mm boom length, it ensures efficient and effective performance on a variety of job sites. The 330B is equipped with water-cooled, turbocharged, and after-cooled technology, providing reliable operation even under demanding conditions.
- Rated power: 165.5 kW at 1800 rpm
- Maximum digging depth: 8080 mm
- Travel speed: 4.6 km/h
- Fuel tank capacity: 560 L
- Total transport dimensions: 11080 mm (length) x 3340 mm (width) x 3610 mm (height)
Located in 甘肃, this unit is ready to integrate seamlessly into your existing fleet, offering the reliability and durability you expect from Caterpillar. Whether as a primary or backup machine, the 330B is designed to handle tough jobs with ease, making it a valuable asset for any construction project.
| Specifications | Value |
|---|---|
| No. | 1023334 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 32420 |
| Bucket capacity (m³) | 1.5 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 3900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar 3306TA |
| Rated power (kw/rpm) | 165.5/1800 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 10.5 |
| Working form | Turbocharging; after-cooling |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 480 |
| Fuel Tank (L) | 560 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 45 |
| Hydraulic System (L) | 400 |
| Total transport length (mm) | 11080 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3610 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1260 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4040 |
| Maximum digging depth (mm) | 8080 |
| Maximum excavation height (mm) | 10770 (Cutting) |
| Maximum unloading height (mm) | 7600 |
| Maximum vertical digging depth (mm) | 7230 |
| Maximum excavation radius of stop surface (mm) | 11620 |
| Travel speed (km/h) | 4.6 |
Overview
No.1023334
Brand Name:
CaterpillarModel Number:
330BYear:
2017
Location:
Gansu China
Pub Date:
