2020 Caterpillar 330C
Product Description
Built for serious excavation work, this 2020 Caterpillar 330C is site-ready and available now from Sichuan, China. Powered by a Caterpillar C9 six-cylinder engine producing 182 kW, this 30-ton machine delivers the raw hydraulic force needed for deep digging, precision grading, and heavy demolition — with a main overflow pressure of 34.3 MPa and a maximum pump flow of 560 l/min keeping performance consistent under load.
Equipped with a 1.7 m³ backhoe bucket and a maximum excavation radius of 11,631 mm, this machine handles large-scale earthmoving without compromise. Maximum excavation height reaches 8,117 mm, while a vertical digging depth of 7,340 mm makes it ideal for deep foundation and trench work.
- Engine: Caterpillar C9 | 6 Cylinders | 8.8L Displacement
- Rated Power: 182 kW
- Working Weight: 35,108 kg
- Bucket Capacity: 1.7 m³ (Backhoe)
- Max Excavation Radius: 11,631 mm
- Max Digging Depth: 7,340 mm
- Fuel Tank: 617 L | Hydraulic System: 174 L
- Travel Speed: 5.0 km/h (Max)
- Location: Sichuan, China — Available for immediate deployment
| Specifications | Value |
|---|---|
| No. | 1137623 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 35108 |
| Bucket capacity (m³) | 1.7 |
| Country of origin | USA, Japan, Belgium, Brazil, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C9 |
| Rated power (kw/rpm) | 182 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.8 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 560 |
| Fuel Tank (L) | 617 |
| Hydraulic System (L) | 174 |
| Total transport length (mm) | 11201 |
| Total transport width (mm) | 3429 |
| Total transport height (mm) | 3734 |
| Minimum ground clearance (mm) | 488 |
| Back end turning radius (mm) | 3505 |
| Track gauge (mm) | 2591 |
| Track plate width (mm) | 864 |
| Total track width (mm) | 3429 |
| Track ground length (mm) | 4039 |
| Maximum excavation height (mm) | 8117 |
| Maximum unloading height (mm) | 7644 |
| Maximum vertical digging depth (mm) | 7340 |
| Maximum excavation radius of stop surface (mm) | 11631 |
| Travel speed (km/h) | 5.0 (Max) |
