Name: Used Excavators 2016 Caterpillar 336E
Brand: Caterpillar
SKU: USED-1050392
Availability: InStock
Rating: 4.9 (23 reviews)

Sany

Caterpillar

XCMG

Hitachi

Komatsu

Doosan

Kobelco

Hyundai

Sumitomo

Volvo

Kato

Case

Yanmar

JohnDeere

Liebherr

Engineered with Caterpillar's renowned C9 ACERT engine delivering 236 kW at 1800 rpm, this 2016 336E excavator represents the pinnacle of mid-size hydraulic machinery. Boasting a 35,500 kg operating weight and 36-ton capacity, this machine combines raw power with precision control through advanced water-cooled systems and optimized hydraulic circuits.

As the first excavator series to meet both European Stage IIIB and Tier 4 emission standards, this unit sets the benchmark for environmental compliance without sacrificing performance. Its 11,040 mm maximum digging radius enables exceptional reach for demanding excavation tasks, while the backhoe configuration delivers versatility across construction and mining applications.

<ul>
<li>Engine: Caterpillar C9 ACERT, 236 kW @ 1800 rpm</li>
<li>Operating Weight: 35,500 kg (36-ton class)</li>
<li>Max Digging Radius: 11,040 mm</li>
<li>Emissions: Stage IIIB / Tier 4 compliant</li>
<li>Location: Fuzhou, Fujian, China</li>
</ul>

Currently located in Fuzhou, Fujian, this joint venture-manufactured unit exemplifies Caterpillar's commitment to hydraulic efficiency and structural durability. Ready

Secure immediate access to this 2018 Sany SY125H excavator, currently positioned in 四川泸州 and ready for rapid deployment. This 12-ton workhorse eliminates factory wait times, delivering proven performance exactly when your project demands it. Equipped with traditional power systems and a versatile backhoe bucket, this Chinese-manufactured machine offers the reliability Sany built its reputation on.

<ul>
<li>12-ton operating capacity for mid-range excavation tasks</li>
<li>Traditional power configuration ensures straightforward maintenance</li>
<li>Backhoe bucket included for immediate productivity</li>
<li>Located in 四川泸州 for fast regional deployment</li>
<li>2018 model year with documented service history</li>
<li>Available now—bypass months of factory lead times</li>
</ul>

Skip the procurement delays that stall project timelines. This SY125H stands ready in 四川泸州, offering same-region logistics advantages that translate to lower transport costs and faster mobilization. Contact us today to arrange inspection and coordinate delivery to your site within days, not months.

Sany SY125H

Engineered with precision hydraulics and proven Kubota V3300-DI power, this 2016 Doosan DH80 delivers 45.8kW at 2200rpm through a water-cooled 3.3L displacement system. The 8-ton excavator combines a maximum main pump flow of 162.8 l/min with robust hydraulic circuits—250 Mpa for travel, 190 Mpa for rotation—ensuring responsive control across all operations. Bucket digging force reaches 55kN while rod digging force achieves 38kN, supported by optimized cylinder configurations throughout the boom, arm, and bucket systems.

Built at Doosan's joint-venture facility in Yantai, Shandong Province, this model features a 3100mm boom and 1800mm arm for a maximum digging reach of 6170mm and depth of 4060mm. The 0.28-0.32m³ backhoe bucket handles diverse excavation tasks with fuel efficiency rated at 163g/ps·hr. Standard hydraulic crushing pipeline integration expands attachment versatility. Compact transport dimensions of 5920mm length by 2200mm width enable easy mobilization between jobsites.

Currently located in Jinhua, Zhejiang Province, this DH80 represents Doosan's commitment to hydraulic efficiency and operational reliability in the compact excavator segment.

Doosan DH80

With a working weight of 5960 kg and a bucket capacity ranging from 0.09 to 0.23 m³, the 2025 XCMG XE60 excavator is an ideal addition to any contractor's fleet. Located in Anhui, this 6-ton machine is powered by a Yanmar 4TNV94L engine, delivering 39.8 kW at 2200 rpm. Featuring a boom length of 3000 mm and a rod length of 1600 mm, it offers impressive digging forces of 42.5 kN for the bucket and 28.5 kN for the rod. The XE60 is equipped with a Rexroth main pump, ensuring reliable performance and efficiency. Its compact dimensions, including a total transport length of 5850 mm and a width of 1880/1920 mm, make it highly maneuverable on tight job sites. With a maximum digging depth of 3830 mm and a maximum unloading height of 3945 mm, this excavator is perfect for a variety of construction and excavation tasks.
<ul>
 <li>Made in China, with a robust design suitable for heavy-duty applications</li>
 <li>Water-cooled engine with a displacement of 3.054 L and 4 cylinders</li>
 <li>Travel speed of 4.2/2.2 km/h, enhancing mobility on various terrains</li>
 <li>Ground specific pressure of 32.1 Kpa, minimizing ground disturbance</li>
 <li>Hydraulic crushing pipeline included as standard, adding versatility to your fleet</

XCMG XE60

Proven in demanding construction environments since 2020, this XCMG XE135B excavator from Anhui demonstrates the durability that has made it a reliable workhorse across job sites. Operating at 13 tons with a 13,800 kg working weight, this machine delivers consistent performance through its ISUZU BB-4BG1TRP engine producing 69.6 kW at 2200 rpm. Built to last with a robust water-cooled turbocharged system and dual plunger pumps providing 2×123 l/min flow, it handles tough excavation tasks with 85 kN bucket digging force and 65 kN rod digging force.

<ul>
 <li>Maximum digging reach: 8,296 mm with 5,538 mm depth capability</li>
 <li>Bucket capacity: 0.4-0.52 m³ for versatile material handling</li>
 <li>Travel speed: 5.16/3.03 km/h with 35° climbing ability</li>
 <li>Boom/rod configuration: 4,600 mm/2,510 mm for optimal reach</li>
 <li>Hydraulic system: 31.4/34.3 MPa main overflow pressure</li>
 <li>Fuel capacity: 250L for extended operation cycles</li>
</ul>

With four years of proven field performance, this Xuzhou-manufactured excavator represents dependable Chinese engineering ready for immediate deployment in medium-duty applications worldwide.

XCMG XE135B

Built for demanding operations, this 2016 Sany SY700C delivers 70-ton performance with operator-centric engineering. Powered by a 298kW turbocharged engine, this excavator combines robust digging force with refined handling characteristics. The 68,000 kg working weight provides exceptional stability across varied terrain, while the 3.5 m³ backhoe bucket tackles high-volume earthmoving with efficiency.

Operator comfort drives productivity on extended shifts. Standard cab design from this era prioritizes visibility across the 11,460 mm working radius, with strategically positioned glazing for monitoring bucket positioning and site surroundings. Hydraulic responsiveness benefits from dual 450 l/min pumps operating at 31.4 MPa, delivering smooth control during precision work. The 6.7 rpm rotation speed enables fluid positioning without compromising stability on the 600 mm track plates.

<ul>
<li>Maximum digging depth: 7,210 mm for deep excavation work</li>
<li>Bucket digging force: 350 kN with 300 kN rod force</li>
<li>Ground pressure: 100 kPa minimizes surface disruption</li>
<li>70% climbing ability handles challenging gradients</li>
<li>Currently located in Luzhou, Sichuan</li>
</ul>

Sany SY700C

Proven in demanding conditions since 2011, this Caterpillar 306D hydraulic excavator represents over a decade of reliable performance. Built with Caterpillar's legendary engineering standards, this compact machine has demonstrated its durability through years of operation in Guizhou's challenging terrain. Its hydraulic system delivers consistent power and precision, making it a dependable workhorse for excavation, trenching, and site preparation tasks.

<ul>
<li>Year: 2011</li>
<li>Brand: Caterpillar</li>
<li>Model: 306D Hydraulic Excavator</li>
<li>Location: Guizhou, China</li>
</ul>

Designed to withstand rigorous daily use, the 306D showcases Caterpillar's commitment to longevity and operational efficiency. Its track record speaks volumes about the machine's structural integrity and mechanical resilience. For contractors seeking a cost-effective solution backed by proven performance, this excavator offers the reliability Caterpillar is known for worldwide. Contact Fair Trade Machinery today to secure this enduring piece of equipment for your fleet.

Caterpillar 306D

Delivering proven performance since 2015, this Doosan DH215-9 excavator from Chongqing represents exceptional value for operations requiring reliable 21-ton capacity without new equipment premiums. Powered by the robust Doosan DE08TIS engine producing 110kW at 1950rpm, this machine combines fuel efficiency with consistent hydraulic output through its dual 211 l/min variable piston pumps. With 9970mm maximum digging radius and 6660mm dig depth, the DH215-9 handles demanding earthmoving tasks across construction, mining, and infrastructure projects.

<ul>
<li>Operating weight: 21,000kg with 0.86-1.0m³ bucket capacity</li>
<li>Water-cooled 6-cylinder engine (8.071L displacement) built for extended duty cycles</li>
<li>5700mm boom and 2900mm arm configuration for versatile reach</li>
<li>Dual axial plunger travel motors and 32.4 MPa hydraulic circuit</li>
<li>Transport dimensions: 9600×2800×2870mm</li>
<li>Joint venture manufacturing from Yantai, Shandong Province</li>
</ul>

Acquire professional-grade excavation capability at a fraction of replacement cost. This Chongqing-based unit offers immediate deployment for budget-conscious contractors seeking Doosan quality and performance without new equipment depreciation.

Doosan DH215-9

Expand your operational capacity with this 2016 Sany SY205C excavator, currently located in Anhui and ready for immediate fleet integration. Built for contractors managing multiple jobsites simultaneously, this 20-ton workhorse delivers consistent performance when your primary machines are committed elsewhere. Powered by a robust 118kW engine, it tackles demanding excavation tasks with 138kN bucket digging force and reaches depths up to 6.6 meters—specifications that match or exceed project requirements across construction, demolation, and earthmoving applications.

<ul>
<li>Operational Specs: 21,500kg working weight | 0.9-1.1m³ bucket capacity | 10.28m maximum digging reach</li>
<li>Performance: 70% grading ability | 5.4km/h travel speed | 11rpm rotation for efficient load cycles</li>
<li>Transport Dimensions: 9,680mm length | 2,980mm width | 3,440mm height for straightforward logistics</li>
<li>Jobsite Versatility: 440mm ground clearance | 3,730mm front turning radius for confined-space maneuverability</li>
</ul>

Acquire proven Chinese engineering at competitive pricing. This machine slots seamlessly into existing Sany fleets or serves as cost-effective ba

Sany SY205C

With a working weight of 20,500 kg and a bucket capacity of 0.9-0.92 m³, this 2019 Volvo EC210B excavator is ready for immediate deployment from 浙江杭州. Skip the factory lead times and get your project moving with this reliable machine. Powered by a Volvo D6D engine, it delivers 107 kW at 1900 rpm, ensuring robust performance. The EC210B boasts a maximum digging depth of 6730 mm and a maximum unloading height of 6650 mm, making it ideal for a wide range of construction and excavation tasks. Its fast travel speed of up to 5.5 km/h and a climbing ability of 70% (35°) ensures quick and efficient movement on-site. Available now, this excavator can be rapidly deployed to your location, minimizing downtime and maximizing productivity.
<ul>
 <li>Working weight: 20,500 kg</li>
 <li>Bucket capacity: 0.9-0.92 m³</li>
 <li>Engine: Volvo D6D, 107 kW at 1900 rpm</li>
 <li>Maximum digging depth: 6730 mm</li>
 <li>Travel speed: 5.5 km/h</li>
 <li>Location: 浙江杭州</li>
</ul>

Volvo EC210B

With a working weight of 38,500 kg and a bucket capacity ranging from 1.9 to 2.1 m³, the XCMG XE380GK excavator, located in 浙江杭州, stands as a smart investment for your construction needs. Powered by fuel oil, this machine delivers 254KW of rated power and boasts a robust 292KN bucket digging force, ensuring high performance on any job site. Capable of reaching a maximum digging depth of 10,508 mm, it is designed for efficiency and durability. Made in China, this 2024 model offers the same reliability and functionality as a new unit but at a fraction of the cost. Invest wisely with the XCMG XE380GK, where high performance meets cost-effectiveness.

XCMG XE380GK

With a solid 7 tons of operational power, this 2012 Hitachi ZX70-6 excavator, located in 浙江杭州, stands as a testament to enduring engineering. Built to last, it has consistently proven its reliability and performance over the years. Featuring a traditional power system, this model is a joint venture/import, ensuring robust construction and dependable operation. Equipped with a backhoe bucket, it excels in a variety of excavation tasks, making it a versatile asset for any construction site. This machine's longevity and proven record make it a reliable choice for contractors who value durability and efficiency.
<ul>
 <li>7-ton capacity</li>
 <li>Traditional power system</li>
 <li>Joint venture/import manufacturer</li>
 <li>Backhoe bucket</li>
 <li>Located in 浙江杭州</li>
</ul>

Hitachi ZX70-6

Located in 浙江杭州, this 2011 Volvo EC210B excavator is available now, ready for immediate deployment to your site. With a working weight of 20,500 kg and a bucket capacity of 0.9-0.92 m³, it ensures robust performance. Powered by a Volvo D6D engine, delivering 107 kW at 1900 rpm, this machine offers reliable and efficient operation. Skip the factory lead times and benefit from fast logistics, ensuring minimal downtime and quick integration into your operations.
<ul>
<li>Boom length: 5700 mm, Rod length: 2900 mm</li>
<li>Maximum travel speed: 3.2/5.5 km/h</li>
<li>Maximum digging depth: 6730 mm</li>
<li>Bucket digging force: 136.3 kN (Standard mode) / 147.1 kN (Extra mode)</li>
<li>Fuel tank capacity: 350 L</li>
</ul>

With a working weight of 6700 kg and a bucket capacity ranging from 0.33 to 0.38 m³, this 2014 Hitachi ZX70-5A excavator is designed for efficient digging, grading, and demolition tasks. Equipped with a 4TNV98 engine, it delivers 42.4 kW of power at 2100 rpm, ensuring robust performance on any job site. The machine features a 3720 mm boom and a 1620 mm rod, providing a maximum digging depth of 4170 mm and a maximum digging radius of 6320 mm. Its 4-stroke, water-cooled, direct injection engine and 3 variable axial piston pumps ensure smooth and reliable operation. The ZX70-5A boasts a maximum tractive force of 47.8 kN and a travel speed of 3.4-5.0 km/h, making it highly maneuverable. Located in 浙江杭州, this excavator is ready to work, offering a combination of power, precision, and durability for your construction needs.

Hitachi ZX70-5A

Featuring a robust 209 kW Hino J08E engine, this 2018 Kobelco SK380D excavator delivers reliable performance and efficiency. With a working weight of 36,900 kg and a bucket capacity of 1.9 m³, it is designed for demanding construction and excavation tasks. The direct injection, turbocharged, and intercooled engine ensures optimal power and fuel economy.
<ul>
<li>Equipped with a backhoe bucket, providing a digging force of 221 kN (supercharged 244 kN), enhancing productivity and versatility.</li>
<li>Two sets of two-speed plunger motors and a double variable axial piston pump, offering smooth and precise control during operation.</li>
<li>The full cab height of 3,233 mm and a minimum ground clearance of 500 mm ensure excellent visibility and stability on the job site.</li>
<li>Maximum travel speed of 5.6 km/h and a climbing ability of 70% (35 degrees) make it suitable for various terrains and conditions.</li>
<li>Located in 浙江杭州, this machine is ready to handle your next project with ease and reliability.</li>
</ul>

Kobelco SK380D

Equipped with a Volvo VOLVO_D13-T4(A) engine, this 2016 Volvo EC480D delivers 245 kW of power, ensuring robust performance. Featuring a piston-type main pump with a maximum flow of 2*358 l/min, it provides efficient and reliable hydraulic operations. The machine meets European Stage IIIB emission requirements, combining power with environmental responsibility.
<ul>
<li>Working weight: 47,900-50,500 kg</li>
<li>Bucket capacity: 1.77-3.80 m³</li>
<li>Boom length: 7,000 mm; Rod length: 4,800 mm</li>
<li>Rated power: 245 kW at 1,800 rpm</li>
<li>Hydraulic system: Water-cooled, with a working pressure of 32.4/35.3 Mpa</li>
</ul>
Designed for durability and precision, the EC480D boasts a 35% climbing ability and a ground specific pressure of 73.7 Kpa, making it ideal for challenging terrains. Its advanced hydraulic system and robust construction ensure optimal performance in various applications, from excavation to material handling.

Volvo EC480D

With a robust 49-ton working weight and a powerful QSM111 engine, this 2017 XCMG XE490D excavator is an ideal fleet addition for busy contractors. Located in 浙江杭州, it offers a bucket capacity of 2.5 m³, making it versatile for various excavation tasks. The 6-cylinder, 11-liter displacement engine provides a rated power of 280 kW at 2050 rpm, ensuring reliable performance on any job site.
<ul>
 <li>Maximum digging force: 305 kN (bucket), 275 kN (rod)</li>
 <li>Travel speed: 5.4 / 3.2 km/h</li>
 <li>Maximum tractive force: 338 kN</li>
 <li>Ground specific pressure: 85 Kpa</li>
 <li>Fuel tank capacity: 725 L</li>
 <li>Total transport dimensions: 11630 mm (length) x 3582 mm (width) x 3705 mm (height)</li>
</ul>
This excavator integrates seamlessly into your existing fleet, providing the necessary support during peak workloads. Its water-cooled, direct injection, 4-stroke, turbocharged, and air-to-air cooling system ensures efficient and continuous operation. Add this durable and high-performing XE490D to your fleet for enhanced productivity and reliability.

Specifications	Value
No.	1050392
Tonnage (tons)	36
Working weight (kg)	35500
power	Traditional power
manufacturer	Joint venture/Import
bucket	backhoe
Engine type	Caterpillar CAT C9ACERT
Rated power (kw/rpm)	236/1800
Cooling mode	water-cooling
Working form	The first excavator to meet European Stage IIIB and Tier4 emission standards
Maximum digging radius (mm)	11040

2016 Caterpillar 336E
