2019 Caterpillar 390DL
Product Description
Discover the robust performance and reliability of the 2019 Caterpillar 390DL, now available for purchase in Sichuan, China. This used heavy machine, priced at over 910,000 CNY, is a testament to Caterpillar's commitment to excellence in construction and excavation. Designed for demanding jobsites, the 390DL offers powerful digging force, superior fuel efficiency, and advanced technology to enhance productivity and lower operating costs. Ideal for large-scale earthmoving, mining, and infrastructure projects, this excavator is equipped with features that ensure durability and ease of maintenance, making it a valuable addition to any fleet.
- Year: 2019
- Brand: Caterpillar
- Model: 390DL
- Location: Sichuan, China
- Price: Over 910,000 CNY
| Specifications | Value |
|---|---|
| No. | 1165810 |
| Tonnage (tons) | 90 |
| Working weight (kg) | 90390 |
| Bucket capacity (m³) | 4.6 |
| Boom length (mm) | 8400 |
| Rod length (mm) | 4400 |
| Country of origin | America |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C18 ACERT(ATAAC) |
| Rated power (kw/rpm) | 390 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 145 x 171 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 18.1 |
| Ground specific pressure (Kpa) | 88.3-122.4 |
| Rotation speed (rpm) | 5.9 |
| Bucket digging force (kN) | 363 |
| Rod digging force (kN) | 276 |
| Maximum tractive force (kN) | 590 |
| Travel speed (km/h) | 4.5 |
| Turning torque (kN/m) | 260 |
| Main overflow set pressure (Mpa) | 35 |
| Type of walking hydraulic motor | 980 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 35 |
| Control Hydraulic Circuit (Mpa) | 26 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Pilot pump flow (L/min) | 90 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-210 x 2262 |
| Fuel Tank (L) | 1240 |
| Engine Oil changes (L) | 65 |
| Coolant (L) | 101 |
| Hydraulic System (L) | 995(including fuel tank) |
| Total transport length (mm) | 14700 |
| Total transport width (mm) | 4260 |
| Total transport height (mm) | 5290 |
| Full cab height (mm) | 3760 |
| Minimum ground clearance (mm) | 900 |
| Back end turning radius (mm) | 4680 |
| Total track length (mm) | Standard 5840/ Extended 6360 |
| Track gauge (mm) | 3510 |
| Track plate width (mm) | 650/750/900 |
| Total track width (mm) | 4260 |
| Maximum digging depth (mm) | 9660 |
| Maximum unloading height (mm) | 9270 |
| Maximum vertical digging depth (mm) | 6850 |
| Maximum excavation radius of stop surface (mm) | 14690 |
| Maximum effective digging depth (mm) | 9550 |
see more
Overview
No.1165810
Brand Name：
CaterpillarModel Number：
390DLYear：
2019
Location：
Sichuan China
