2020 Caterpillar CAT307.5
Product Description
This 2020 Caterpillar CAT307.5 mini excavator offers reliable performance for contractors and earthmoving professionals. With low operating hours, this compact machine delivers the durability and efficiency Caterpillar is known for in the construction equipment industry. The CAT307.5 features a tight tail swing radius for working in confined spaces, making it ideal for urban construction, landscaping, and utility installation projects.
Key features include:
- Caterpillar C2.4 engine for fuel-efficient operation
- Hydraulic quick coupler compatibility
- Comfortable operator cabin with excellent visibility
- Robust undercarriage designed for extended service life
- Currently located in Guangdong, China
This machine represents an excellent opportunity to acquire proven Caterpillar quality at a competitive price point. Suitable for rental fleets, contractors, or businesses expanding their equipment inventory. Contact us for detailed specifications, inspection reports, and export documentation assistance.
| Specifications | Value |
|---|---|
| No. | 1158504 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7504-8113 |
| Bucket capacity (m³) | UD 0.33 |
| Rod length (mm) | 1665 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cat® C2.4T |
| Rated power (kw/rpm) | 36.5/2400 |
| Cylinder diameter × stroke (mm) | 87*102 |
| Displacement (L) | 2.43 |
| Emission standard | Country IV |
| Ground specific pressure (Kpa) | 35.2 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 54.6 |
| Rod digging force (kN) | 37.8 |
| Maximum tractive force (kN) | 62.4 |
| Travel speed (km/h) | 3.1~5.0 |
| Maximum flow of main pump (l/min) | 167 |
| Traveling Hydraulic Circuit (Mpa) | 28.5 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Working Hydraulic Circuit (Mpa) | 28.5 |
| Fuel Tank (L) | 145 |
| Hydraulic Tank (L) | 53 |
| Engine Oil changes (L) | 9.5 |
| Coolant (L) | 10 |
| Hydraulic System (L) | 104 |
| Total transport length (mm) | 6130 |
| Total transport height (mm) | 2569 |
| Minimum ground clearance (mm) | 370 |
| Back end turning radius (mm) | 1800/1995 |
| Onboard width (mm) | 2250 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2200 |
| Maximum digging radius (mm) | 6297 |
| Maximum digging depth (mm) | 4047 |
| Maximum excavation height (mm) | 7401 |
| Maximum unloading height (mm) | 5353 |
| Maximum vertical digging depth (mm) | 3544 |
| Bulldozer lift or depth (mm) | 363/414 |
| Dodging plate width × height (mm) | 2280*431 |
| Manufacturer's guide price (Yuan) | 368,000 |
Overview
No.1158504
Brand Name：
CaterpillarModel Number：
CAT307.5
Year：
2020
Location：
Guangdong China
