2020 Caterpillar E200B






Product Description
Route power through a proven CAT 3116 engine — 88 kW at 1,800 rpm — and put a 20-ton class machine on the dig. The E200B carries a 0.57–1.1 m³ backhoe bucket, a 5,680 mm maximum digging depth, and a 250 L hydraulic reservoir sized for sustained output.
Where it counts is the name on the hood. Caterpillar's parts network reaches worldwide, so filters, hoses, and undercarriage spares stay within reach long after purchase. That availability keeps uptime high and rebuilds economical. It also protects resale value: buyers pay a premium for Cat iron because the support is predictable, year after year.
- 18,800 kg operating weight; 20 t class
- 5.0 km/h travel speed; 600 mm track plates
- 2,750 mm rear swing radius for tight sites
| Specifications | Value |
|---|---|
| No. | 1140772 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 18800 |
| Bucket capacity (m³) | 0.57/0.38/1.1 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR 3116 |
| Rated power (kw/rpm) | 88/1800 |
| Displacement (L) | 6.6 |
| Ground specific pressure (Kpa) | 43.4 |
| Travel speed (km/h) | 5 |
| Fuel Tank (L) | 280 |
| Engine Oil changes (L) | 15 |
| Coolant (L) | 23 |
| Hydraulic System (L) | 250 |
| Total transport length (mm) | 9705 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3015 |
| Full cab height (mm) | 2830 |
| Counterweight ground clearance (mm) | 1030 |
| Minimum ground clearance (mm) | 465 |
| Back end turning radius (mm) | 2750 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Maximum digging depth (mm) | 5680 |
| Maximum excavation height (mm) | 8880 |
| Maximum unloading height (mm) | 6050 |
| Maximum vertical digging depth (mm) | 4820 |
| Maximum excavation radius of stop surface (mm) | 8850 |
Overview
No.1140772
Brand Name:
CaterpillarModel Number:
E200BYear:
2020
Location:
Guangdong China
Pub Date:
