2016 Caterpillar M318D
Product Description
Built for demanding jobsites, this 2016 Caterpillar M318D wheeled excavator delivers reliable performance across urban construction, road maintenance, and utility projects. Powered by the proven CATERPILLAR C6.6 Acert engine generating 129.8 kW, this 18-ton machine combines mobility with excavation power. The 8970mm maximum excavation radius and 5750mm digging depth handle trenching, grading, and loading operations with precision.
- 20,100 kg working weight with three bucket configurations (0.74/0.57/1.6 m³) for versatile applications
- 37 km/h forward speed enables rapid repositioning between work zones without transport trailers
- 9710mm maximum excavation height reaches multi-story demolition and elevated loading tasks
- 35 MPa hydraulic system delivers consistent breakout force and cycle times
- 2550mm transport width navigates congested sites and public roads legally
- 386L fuel capacity supports extended shifts without refueling downtime
Currently located in Luzhou, Sichuan, this joint-venture manufactured unit arrives inspection-ready with complete specifications documented. Hydraulic system holds 268.8L, engine oil capacity at 15.1L—maintenance records
| Specifications | Value |
|---|---|
| No. | 1033949 |
| Tonnage (tons) | 18 |
| Working weight (kg) | 20100 |
| Bucket capacity (m³) | 0.74/0.57/1.6 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR C6.6 Acert |
| Rated power (kw/rpm) | 129.8/123.8 |
| Total displacement (L) | 6.6 |
| Forward speed (Km/h) | 37 |
| Rotation speed (rpm) | 10.5 |
| Main overflow set pressure (Mpa) | 35 |
| Fuel Tank (L) | 386.1 |
| Engine Oil changes (L) | 15.1 |
| Coolant (L) | 32.2 |
| Hydraulic System (L) | 268.8 |
| Total transport length (mm) | 8870 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3170 |
| Full cab height (mm) | 3170 |
| Counterweight ground clearance (mm) | 1280 |
| Wheelbase (mm) | 2600 |
| Total tire outside width (mm) | 2550 |
| Minimum ground clearance (mm) | 370 |
| Back end turning radius (mm) | 2500 |
| Maximum excavation radius (mm) | 8970 |
| Maximum digging depth (mm) | 5750 |
| Maximum excavation height (mm) | 9710 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 3220 |
see more
Overview
No.1033949
Brand Name：
CaterpillarModel Number：
M318DYear：
2016
Location：
Sichuan China
Pub Date：
