2020 Caterpillar M318D








Product Description
Discover the robust and reliable 2020 Caterpillar M318D excavator, now available in Zhejiang, China. This machine is a testament to Caterpillar's commitment to durability and performance, making it an ideal choice for demanding construction and excavation projects. With detailed images and extensive video documentation available, you can be confident in the condition and capabilities of this unit.
- Year: 2020
- Brand: Caterpillar
- Model: M318D
- Location: Zhejiang, China
| Specifications | Value |
|---|---|
| No. | 1082484 |
| Tonnage (tons) | 18 |
| Working weight (kg) | 20100 |
| Bucket capacity (m³) | 0.74/0.57/1.6 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR C6.6 Acert |
| Rated power (kw/rpm) | 129.8/123.8 |
| Total displacement (L) | 6.6 |
| Forward speed (Km/h) | 37 |
| Rotation speed (rpm) | 10.5 |
| Main overflow set pressure (Mpa) | 35 |
| Fuel Tank (L) | 386.1 |
| Engine Oil changes (L) | 15.1 |
| Coolant (L) | 32.2 |
| Hydraulic System (L) | 268.8 |
| Total transport length (mm) | 8870 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3170 |
| Full cab height (mm) | 3170 |
| Counterweight ground clearance (mm) | 1280 |
| Wheelbase (mm) | 2600 |
| Total tire outside width (mm) | 2550 |
| Minimum ground clearance (mm) | 370 |
| Back end turning radius (mm) | 2500 |
| Maximum excavation radius (mm) | 8970 |
| Maximum digging depth (mm) | 5750 |
| Maximum excavation height (mm) | 9710 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 3220 |
see more
Overview
No.1082484
Brand Name:
CaterpillarModel Number:
M318DYear:
2020
Location:
Zhejiang China
Pub Date:
