Product Description
This 2020 Doosan 150W-7 excavator represents a well-maintained unit currently located in Beijing, China. The machine features original factory paint throughout, indicating careful operation and storage conditions. All major components—engine, hydraulic pump, and main control valve—are reported in excellent working condition with no fluid leaks, demonstrating proper maintenance protocols during its operational life.
This excavator has been utilized exclusively for standard excavation work, ensuring consistent operational patterns without exposure to extreme applications. The Doosan 150W-7 series is recognized for reliable performance in medium-duty construction and earthmoving applications.
- Year of Manufacture: 2020
- Model: Doosan 150W-7
- Current Location: Beijing, China
- Condition: Original paint, no major component leaks
- Service History: Standard excavation applications
Suitable for contractors seeking dependable mid-range excavation equipment with verified maintenance records. Inspection recommended prior to purchase.
| Specifications | Value |
|---|---|
| No. | 1138809 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 12900 |
| Bucket capacity (m³) | 0.57 |
| Boom length (mm) | 4300 |
| Rod length (mm) | 2100/2500 |
| Country of origin | Yantai |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | DB58TIS |
| Rated power (kw/rpm) | 96/2200 |
| Cooling mode | Air cooling |
| Cylinder diameter × stroke (mm) | 102 x 118 |
| Number of cylinders (PCS) | 6 |
| Forward speed (Km/h) | 10-37 |
| Rotation speed (rpm) | 12.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 94.1 |
| Rod digging force (kN) | 68.6 |
| Minimum turning radius (m) | 77 |
| Maximum tractive force (kN) | 62 |
| Driving form | Hydraulic drive |
| Maximum flow of main pump (l/min) | 2 x 162 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 26.5 |
| Boom cylinder - Cylinder diameter × stroke (mm) | 2-110 x 1030 |
| Bucket rod cylinder - Cylinder diameter × stroke (mm) | 1-110 x 1085 |
| Bucket cylinder - Cylinder diameter × stroke (mm) | 1-95 x 885 |
| Main pump type | Variable axial plunger pump |
| Working Hydraulic Circuit (Mpa) | Standard 22.7/ Supercharged 34.3 |
| Fuel Tank (L) | 280 |
| Hydraulic Tank (L) | 95 |
| Total transport length (mm) | 7250 |
| Total transport width (mm) | 2495 |
| Total transport height (mm) | 3125(to top of cab) |
| Full cab height (mm) | 3116 |
| Counterweight ground clearance (mm) | 1241 |
| Wheelbase (mm) | 2800 |
| Single tire width (mm) | 582 |
| Total tire outside width (mm) | 2496 |
| Wheel base (mm) | 1914 |
| Minimum ground clearance (mm) | 350 |
| Back end turning radius (mm) | 2210 |
| Maximum digging radius (mm) | 7530 |
| Maximum excavation radius (mm) | 7295/7728 |
| Maximum digging depth (mm) | 4615 |
| Maximum excavation height (mm) | 8015 |
| Maximum unloading height (mm) | 5630 |
| Maximum vertical digging depth (mm) | 4086/4675 |
| Minimum turning radius (mm) | 2210 |
